Side Panels
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2318501-PG Side Panel Assembly, RH | Side Panel Assembly, RH Jet Black - For Jet Black Bikes | 1 | $379.04 | Backorder — Late August 2026 | 1 |
| 1 | T2318501-PS Side Panel Assembly, RH | Side Panel Assembly, RH Matt Jet Black - For Matt Ironstone bikes | 1 | $379.04 | Available to order | 1 |
| 1 | T2318504-PG Side Panel Assembly, RH | Side Panel Assembly, RH Jet Black - For Cobalt Blue Bikes | 1 | $379.04 | Backorder — Late August 2026 | 1 |
| 1 | T2318501-PZ Side Panel Assembly, RH | Side Panel Assembly, RH Matt Sapphire Black - Street Twin Goldline Only | 1 | $379.04 | Out of Stock | Notify Me |
| 1 | T2318501-MT Side Panel Assy, RH, Matt Silver Ice | Side Panel Assy, RH, Matt Silver Ice For Matt Silver Ice/Matt Aluminium Silver Bikes | 1 | $379.04 | Available to order | 1 |
| 2 | T2318502-PG Side Panel Assembly, LH | Side Panel Assembly, LH Jet Black - For Jet Black Bikes | 1 | $379.04 | Available to order | 1 |
| 2 | T2318502-PS Side Panel Assembly, LH | Side Panel Assembly, LH Matt Jet Black - For Matt Ironstone bikes | 1 | $379.04 | Available to order | 1 |
| 2 | T2318505-PG Side Panel Assembly, LH | Side Panel Assembly, LH Jet Black - For Cobalt Blue Bikes | 1 | $379.04 | Available to order | 1 |
| 2 | T2318502-PZ Side Panel Assembly, LH | Side Panel Assembly, LH Matt Sapphire Black - Street Twin Goldline Only | 1 | $379.04 | Out of Stock | Notify Me |
| 2 | T2318502-MT Side Panel Assy, LH, Matt Silver Ice | Side Panel Assy, LH, Matt Silver Ice For Matt Silver Ice/Matt Aluminium Silver Bikes | 1 | $379.04 | Out of Stock | Notify Me |
| 3 | T2313311 Mesh, RH, Panel | Mesh, RH, Panel | 1 | $26.04 | Out of Stock | Notify Me |
| 3 | T2313312 Mesh, LH, Panel | Mesh, LH, Panel | 1 | $26.04 | Out of Stock | Notify Me |
| 4 | T3550253 Washer, Dia 5 mm, Retaining | Washer, Dia 5 mm, Retaining | 6 | $0.97 | Available to order | 6 |
| 5 | T2314136 Decal, Sidepanel, RH | Decal, Sidepanel, RH Jet Black & Matt Ironstone Bikes | 1 | $36.07 | Backorder — Mid August 2026 | 1 |
| 5 | T2314138 Decal, Sidepanel, RH | Decal, Sidepanel, RH Cobalt Blue Bikes | 1 | $36.07 | Available to order | 1 |
| 5 | T2310699 Decal, Sidepanel, RH, Gold | Decal, Sidepanel, RH, Gold Street Twin Goldline Only | 1 | $39.22 | Out of Stock | Notify Me |
| 5 | T2315511 Decal, Sidepanel, Ltd Ed, RH | Decal, Sidepanel, Ltd Ed, RH Matt Silver Ice/Matt Aluminium Silver Bikes | 1 | $71.63 | Backorder — Late August 2026 | 1 |
| 6 | T2314137 Decal, Sidepanel, LH | Decal, Sidepanel, LH Jet Black & Matt Ironstone Bikes | 1 | $36.07 | Out of Stock | Notify Me |
| 6 | T2314139 Decal, Sidepanel, LH | Decal, Sidepanel, LH Cobalt Blue Bikes | 1 | $36.07 | Available to order | 1 |
| 6 | T2310706 Decal, Sidepanel, LH, Gold | Decal, Sidepanel, LH, Gold Street Twin Goldline Only | 1 | $39.22 | Out of Stock | Notify Me |
| 6 | T2315512 Decal, Sidepanel, Ltd Ed, LH | Decal, Sidepanel, Ltd Ed, LH Matt Silver Ice/Matt Aluminium Silver Bikes | 1 | $71.63 | Out of Stock | Notify Me |
| 7 | T3020054 Grommet, Sidepanel | Grommet, Sidepanel | 5 | $2.37 | Out of Stock | Notify Me |
| 8 | T2302776 Infill, Sidepanel, LH | Infill, Sidepanel, LH | 1 | $23.35 | Out of Stock | Notify Me |
| 9 | T3701098 Firtree, Dia 5 x 18 | Firtree, Dia 5 x 18 | 3 | $5.24 | Available to order | 3 |
| 10 | T2305738 Allen Key, 4mm | Allen Key, 4mm | 1 | $5.42 | Available to order | 1 |
