Rear Mudguard
Parts (5)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2313790 Rear Mudguard, Upper, MX | Rear Mudguard, Upper, MX | 1 | $69.76 | Available to order | 1 |
| 2 | T3330446 Bolt, Lge, M6 x 1 x 20, Slv | Bolt, Lge, M6 x 1 x 20, Slv | 2 | $1.78 | Available to order | 2 |
| 3 | T3750041 Insert, Press-In, 6.2 x 11.2 x 6.7 | Insert, Press-In, 6.2 x 11.2 x 6.7 | 2 | $11.62 | Available to order | 2 |
| 4 | T3750035 Insert, Press In, 12 x 4.5 x 7.2 | Insert, Press In, 12 x 4.5 x 7.2 | 2 | $10.79 | Available to order | 2 |
| 5 | T3330469 Bolt, Lge TX, M6 x 20, Enc | Bolt, Lge TX, M6 x 20, Enc | 2 | $1.78 | Available to order | 2 |
