Rear Mudguard
Parts (8)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2313792 Rear Mudguard, Upper, EN | Rear Mudguard, Upper, EN | 1 | $69.76 | Available to order | 1 |
| 2 | T3330446 Bolt, Lge, M6 x 1 x 20, Slv | Bolt, Lge, M6 x 1 x 20, Slv | 2 | $1.78 | Available to order | 2 |
| 3 | T3750035 Insert, Press In, 12 x 4.5 x 7.2 | Insert, Press In, 12 x 4.5 x 7.2 | 2 | $10.79 | Available to order | 2 |
| 4 | T2315301 Mudguard, Rear, Lower | Mudguard, Rear, Lower | 1 | $25.14 | Available to order | 1 |
| 5 | T3336102 Screw, S/Tap, HHF, 6 x 20, PT | Screw, S/Tap, HHF, 6 x 20, PT Qty 3 for US & CA Markets | 6 | $2.74 | Available to order | 6 |
| 6 | T3330469 Bolt, Lge TX, M6 x 20, Enc | Bolt, Lge TX, M6 x 20, Enc | 2 | $1.78 | Available to order | 2 |
| 7 | T2315334 Number Plate Hanger, EC | Number Plate Hanger, EC All Except US & CA | 1 | $12.04 | Available to order | 1 |
| 8 | T3330943 Screw, But/Hd, M5 x 14, Slv | Screw, But/Hd, M5 x 14, Slv | 2 | $4.92 | Available to order | 2 |
