Rear Bodywork
Parts (11)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2313663 Cover, Airbox, LH, Mldg | Cover, Airbox, LH, Mldg | 1 | $64.66 | Available to order | 1 |
| 2 | T2313667 Cover Airbox, RH, Mldg | Cover Airbox, RH, Mldg | 1 | $64.66 | Available to order | 1 |
| 5 | T2314450 Cover Panel, Air Filter | Cover Panel, Air Filter | 1 | $32.16 | Available to order | 1 |
| 5 | T2314449 Vented Panel, Air Filter | Vented Panel, Air Filter US & CA Only - Supplied with Bike | 1 | $23.76 | Available to order | 1 |
| 6 | T3330446 Bolt, Lge, M6 x 1 x 20, Slv | Bolt, Lge, M6 x 1 x 20, Slv | 1 | $1.78 | Available to order | 1 |
| 7 | T3750036 Insert, Press-In, Sltd, 13 x 15.5 x 6 | Insert, Press-In, Sltd, 13 x 15.5 x 6 | 1 | $18.03 | Available to order | 1 |
| 8 | T3350503 Insert, Press In | Insert, Press In | 2 | $5.19 | Available to order | 2 |
| 9 | T2313262 Decal, Model, TF250E | Decal, Model, TF250E | 2 | $28.75 | Available to order | 2 |
| 10 | T3555026 Washer, 6.4 x 18 x 1.6 | Washer, 6.4 x 18 x 1.6 | 1 | $1.21 | Available to order | 1 |
| 11 | T3750042 Insert, Press-In, 8 x 13 x 3.7 | Insert, Press-In, 8 x 13 x 3.7 | 1 | $10.40 | Available to order | 1 |
| 12 | T3330451 Bolt, Lge, TX, M6 x 30, Slv | Bolt, Lge, TX, M6 x 30, Slv | 1 | $1.78 | Available to order | 1 |
