Crankshaft, Connecting Rods & Pistons
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1105006 Crankshaft Assembly | Crankshaft Assembly | 1 | $1030.00 | Available to order | 1 |
| 5 | T1105037 Thrust Washer, ID33 x 0.025 | Thrust Washer, ID33 x 0.025 Use as required | — | $7.43 | Available to order | 1 |
| 5 | T1105061 Thrust Washer, ID33 x 0.1 | Thrust Washer, ID33 x 0.1 Use as required | — | $4.88 | Available to order | 1 |
| 5 | T1105062 Thrust Washer, ID33 x 0.15 | Thrust Washer, ID33 x 0.15 Use as required | — | $4.45 | Available to order | 1 |
| 5 | T1105073 Thrust Washer, ID33 x 0.2 | Thrust Washer, ID33 x 0.2 Use as required | — | $4.88 | Available to order | 1 |
| 5 | T1105074 Thrust Washer, ID33 x 0.25 | Thrust Washer, ID33 x 0.25 Use as required | — | $4.45 | Available to order | 1 |
| 5 | T1105063 Thrust Washer, ID33 x 0.3 | Thrust Washer, ID33 x 0.3 Use as required | — | $4.88 | Available to order | 1 |
| 6 | T1120079 Piston Kit | Piston Kit | 1 | $294.50 | Available to order | 1 |
| 8 | T1120153 Circlip, Piston, 19 x 1.4 | Circlip, Piston, 19 x 1.4 | 2 | $14.55 | Available to order | 2 |
| 9 | T1120094 Piston Ring Kit | Piston Ring Kit | 1 | $13.69 | Available to order | 1 |
| 10 | T1100056 Conrod Replacement Kit | Conrod Replacement Kit | 1 | $218.18 | Available to order | 1 |
| 11 | T1120178 Piston & Gudgeon Pin Kit | Piston & Gudgeon Pin Kit | 1 | $279.39 | Available to order | 1 |
| 12 | T1100049 Crankshaft Bearing Kit | Crankshaft Bearing Kit | 1 | $194.40 | Available to order | 1 |
| 13 | T1120088 Piston & Gasket Kit | Piston & Gasket Kit | 1 | $317.75 | Available to order | 1 |
