Side Panels
Parts (7)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2310630 Cover, Fuel Tank, LHS | Cover, Fuel Tank, LHS > CB2068 | 1 | $57.47 | Available to order | 1 |
| 1 | T2313890 Cover, Fuel Tank, LHS | Cover, Fuel Tank, LHS CB2069 > | 1 | $59.20 | Available to order | 1 |
| 2 | T2310631 Cover, Fuel Tank, RHS | Cover, Fuel Tank, RHS > CB2068 | 1 | $57.47 | Available to order | 1 |
| 2 | T2313891 Cover, Fuel Tank, RHS | Cover, Fuel Tank, RHS CB2069 > | 1 | $59.20 | Available to order | 1 |
| 3 | T3200662 Bolt, TX, Lghtd, M6 x 16, Slv | Bolt, TX, Lghtd, M6 x 16, Slv | 4 | $2.67 | Available to order | 4 |
| 4 | T3700705 Bushing, OD16 x ID7 | Bushing, OD16 x ID7 | 4 | $8.88 | Available to order | 4 |
| 5 | T3336102 Screw, S/Tap, HHF, 6 x 20, PT | Screw, S/Tap, HHF, 6 x 20, PT | 4 | $2.74 | Available to order | 4 |
