Service Tools
Parts (35)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T3880147 Radiator and Cap Tester | Radiator and Cap Tester | 1 | $139.26 | Available to order | 1 |
| 2 | T3880216 Fork Seal Cleaner, Large | Fork Seal Cleaner, Large | 1 | $18.49 | Available to order | 1 |
| 3 | T3880414 Lithium Battery Charger | Lithium Battery Charger | 1 | $203.40 | Available to order | 1 |
| 4 | T3880432 Battery Charger Power Lead, UK | Battery Charger Power Lead, UK | 1 | $11.67 | Out of Stock | Notify Me |
| 4 | T3880429 Battery Charger Power Lead, EU | Battery Charger Power Lead, EU EU Markets & TH | 1 | $9.00 | Backorder — Early October 2026 | 1 |
| 4 | T3880433 Battery Charger Power Lead, US | Battery Charger Power Lead, US | 1 | $9.82 | Available to order | 1 |
| 4 | T3880430 Battery Charger Power Lead, JP | Battery Charger Power Lead, JP | 1 | $10.19 | Out of Stock | Notify Me |
| 4 | T3880434 Battery Charger Power Lead, AU/NZ | Battery Charger Power Lead, AU/NZ AU, NZ & CA | 1 | $9.64 | Out of Stock | Notify Me |
| 4 | T3880435 Battery Charger Power Lead, IN | Battery Charger Power Lead, IN | 1 | $10.52 | Out of Stock | Notify Me |
| 5 | T3880661 Fork Seal Installer | Fork Seal Installer | 1 | $58.77 | Available to order | 1 |
| 6 | T3880171 Fork Holding Tool | Fork Holding Tool | 1 | $142.88 | Available to order | 1 |
| 7 | T3880538 Diagnostic Interface Cable | Diagnostic Interface Cable | 1 | $58.07 | Available to order | 1 |
| 8 | T3880800 Octagonal Spanner, 49mm | Octagonal Spanner, 49mm | 1 | $29.51 | Available to order | 1 |
| 9 | T3880105 Angular Torque Gauge | Angular Torque Gauge | 1 | $3.47 | Available to order | 1 |
| 10 | T3880001 Fuel Press, Gauge, Returnless | Fuel Press, Gauge, Returnless | 1 | $95.20 | Available to order | 1 |
| 11 | T3880524 LH Engine Case Puller | LH Engine Case Puller | 1 | $45.85 | Available to order | 1 |
| 12 | T3880536 Fork Base Valve Tool | Fork Base Valve Tool | 1 | $7.31 | Available to order | 1 |
| 13 | T3880609 Torque Limiter | Torque Limiter | 1 | $12.30 | Available to order | 1 |
| 14 | T3880629 Bearing Installer Handle | Bearing Installer Handle | 1 | $9.64 | Available to order | 1 |
| 16 | T3880539 Bearing Installer Kit | Bearing Installer Kit | 1 | $25.38 | Available to order | 1 |
| 17 | T3880540 Bearing Installer, 28mm | Bearing Installer, 28mm | 1 | $11.74 | Available to order | 1 |
| 18 | T3880562 Camshaft Timing Tensioner | Camshaft Timing Tensioner | 1 | $16.81 | Available to order | 1 |
| 19 | T3880521 Puller, Alternator Housing | Puller, Alternator Housing | 1 | $14.21 | Available to order | 1 |
| 20 | T3880611 Spring Compressor, Inlet | Spring Compressor, Inlet | 1 | $11.41 | Available to order | 1 |
| 21 | T3880541 Camshaft Timing Plate | Camshaft Timing Plate | 1 | $49.57 | Available to order | 1 |
| 22 | T3880558 Drift Tool, 27mm | Drift Tool, 27mm | 1 | $8.11 | Available to order | 1 |
| 23 | T3880613 6mm Hex Extension | 6mm Hex Extension | 1 | $10.05 | Available to order | 1 |
| 24 | T3880525 Bearing Race Remover | Bearing Race Remover | 1 | $68.79 | Available to order | 1 |
| 25 | T3880543 Diagnostic Interface Adaptor | Diagnostic Interface Adaptor | 1 | $13.19 | Available to order | 1 |
| 26 | T3880552 Tensioner Release Tool | Tensioner Release Tool | 1 | $7.77 | Available to order | 1 |
| 27 | T3880617 Clutch Holder | Clutch Holder | 1 | $2.10 | Available to order | 1 |
| 28 | T3880616 Circlip Insertion Tool | Circlip Insertion Tool | 1 | $4.15 | Available to order | 1 |
| 29 | T3880612 Spring Compressor, Exhaust | Spring Compressor, Exhaust | 1 | $11.41 | Available to order | 1 |
| 30 | T3880520 Locking Pin | Locking Pin | 1 | $3.94 | Available to order | 1 |
| 31 | T3880554 Kit, Crankshaft Bearing Installer | Kit, Crankshaft Bearing Installer | 1 | $23.96 | Available to order | 1 |
