Airbox
Parts (23)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2205739 Airbox, Rear | Airbox, Rear | 1 | $17.77 | Available to order | 1 |
| 2 | T2205737 Airbox, Front | Airbox, Front | 1 | $22.21 | Available to order | 1 |
| 3 | T2208723 Inlet, Airbox Moulding | Inlet, Airbox Moulding | 1 | $64.66 | Available to order | 1 |
| 4 | T2205329 Air Filter, Foam, Assy, Spares | Air Filter, Foam, Assy, Spares | 1 | $26.73 | Available to order | 1 |
| 5 | T2206287 Cage, Filter | Cage, Filter | 1 | $25.38 | Available to order | 1 |
| 6 | T2206282 Strap, Rubber, Air Filter | Strap, Rubber, Air Filter | 1 | $2.42 | Available to order | 1 |
| 7 | T2207357 Infill, Rubber | Infill, Rubber | 1 | $6.73 | Available to order | 1 |
| 8 | T2208858 Inlet, Trumpet, Short | Inlet, Trumpet, Short | 1 | $6.23 | Available to order | 1 |
| 9 | T3336102 Screw, S/Tap, HHF, 6 x 20, PT | Screw, S/Tap, HHF, 6 x 20, PT | 7 | $2.74 | Available to order | 7 |
| 10 | T2205738 Airbox Cover Panel, RHS, Mldg | Airbox Cover Panel, RHS, Mldg | 1 | $4.45 | Available to order | 1 |
| 11 | T2312137 Splash Guard Mldg | Splash Guard Mldg | 1 | $29.89 | Available to order | 1 |
| 12 | T2311740 Washer, Domed, OD22, ID6.6 | Washer, Domed, OD22, ID6.6 | 2 | $6.23 | Available to order | 2 |
| 13 | T2209258 Breather Hose, Engine | Breather Hose, Engine | 1 | $7.19 | Available to order | 1 |
| 14 | T3700076 Hose Clip, 14-15.5 | Hose Clip, 14-15.5 | 1 | $4.98 | Available to order | 1 |
| 15 | T3700248 Clip, Dia 61 | Clip, Dia 61 | 1 | $5.73 | Available to order | 1 |
| 16 | T3331414 Screw, S/Tap, Tx, 5 x 16 | Screw, S/Tap, Tx, 5 x 16 | 1 | $1.51 | Available to order | 1 |
| 17 | T2206992 Grommet, Rubber, Air Filter | Grommet, Rubber, Air Filter | 1 | $2.67 | Available to order | 1 |
| 18 | T2312015 Rubber Grommet | Rubber Grommet | 2 | $1.09 | Available to order | 2 |
| 19 | T3750036 Insert, Press-In, Sltd, 13 x 15.5 x 6 | Insert, Press-In, Sltd, 13 x 15.5 x 6 | 1 | $18.03 | Available to order | 1 |
| 20 | T2209127 Intake Restrictor, EU | Intake Restrictor, EU | 1 | $7.19 | Available to order | 1 |
| 21 | T3330469 Bolt, Lge TX, M6 x 20, Enc | Bolt, Lge TX, M6 x 20, Enc | 2 | $1.78 | Available to order | 2 |
| 22 | T3700035 Clip, Hose, Dia 13.5-15.0 | Clip, Hose, Dia 13.5-15.0 | 1 | $0.75 | Available to order | 1 |
| 23 | T3750043 Insert, Press In, 6 x 11 x 3.7 | Insert, Press In, 6 x 11 x 3.7 | 2 | $7.19 | Available to order | 2 |
