Headlights
Parts (7)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2701547 Headlight, LED, EN | Headlight, LED, EN | 1 | $150.88 | Available to order | 1 |
| 2 | T2701846 Bracket, Headlight | Bracket, Headlight | 1 | $12.94 | Available to order | 1 |
| 3 | T3200662 Bolt, TX, Lghtd, M6 x 16, Slv | Bolt, TX, Lghtd, M6 x 16, Slv | 2 | $2.67 | Available to order | 2 |
| 4 | T3550957 Washer. M6 x 13 | Washer. M6 x 13 | 2 | $1.91 | Available to order | 2 |
| 5 | T3331414 Screw, S/Tap, Tx, 5 x 16 | Screw, S/Tap, Tx, 5 x 16 | 2 | $1.51 | Available to order | 2 |
| 6 | T3331422 Screw, S/Tap, Torx, 5 x 20 | Screw, S/Tap, Torx, 5 x 20 | 1 | $2.63 | Available to order | 1 |
| 7 | T3551066 Washer, 4.3 x 12.0 x 1.0 | Washer, 4.3 x 12.0 x 1.0 | 1 | $1.62 | Backorder — Late September 2026 | 1 |
