Crankshaft, Connecting Rods & Pistons
Parts (13)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1105012 Crankshaft Assembly | Crankshaft Assembly | 1 | $1100.97 | Available to order | 1 |
| 2 | T1100057 Conrod Replacement Kit | Conrod Replacement Kit | 1 | $213.12 | Available to order | 1 |
| 3 | T1105057 Thrust Washer, ID38 x 0.025 | Thrust Washer, ID38 x 0.025 Use as required | — | $12.98 | Available to order | 1 |
| 3 | T1105064 Thrust Washer, ID38 x 0.1 | Thrust Washer, ID38 x 0.1 Use as required | — | $5.24 | Available to order | 1 |
| 3 | T1105065 Thrust Washer, ID38 x 0.15 | Thrust Washer, ID38 x 0.15 Use as required | — | $5.24 | Available to order | 1 |
| 3 | T1105066 Thrust Washer, ID38 x 0.3 | Thrust Washer, ID38 x 0.3 Use as required | — | $4.76 | Available to order | 1 |
| 3 | T1105071 Thrust Washer, ID38 x 0.2 | Thrust Washer, ID38 x 0.2 Use as required | — | $5.24 | Available to order | 1 |
| 3 | T1105072 Thrust Washer, ID38 x 0.25 | Thrust Washer, ID38 x 0.25 Use as required | — | $4.76 | Available to order | 1 |
| 4 | T1120087 Piston Kit | Piston Kit | 1 | $258.64 | Available to order | 1 |
| 5 | T1120095 Piston Ring Kit | Piston Ring Kit | 1 | $21.66 | Available to order | 1 |
| 6 | T1120105 Circlip, Piston, 22.3 x 1.6 | Circlip, Piston, 22.3 x 1.6 | 2 | $9.52 | Available to order | 2 |
| 7 | T1100058 Crankshaft Bearing Kit | Crankshaft Bearing Kit | 1 | $340.50 | Available to order | 1 |
| 8 | T1120089 Piston & Gasket Kit | Piston & Gasket Kit | 1 | $279.55 | Available to order | 1 |
