Rear Light
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | TA401017 Tail Lamp | Tail Lamp All except US | 1 | $42.18 | Backorder — Late August 2026 | 1 |
| 2 | TA401006 Number Plate Lamp | Number Plate Lamp | 1 | $44.81 | Available to order | 1 |
| 3 | LBR00003 Screw, Tapping, Pan | Screw, Tapping, Pan | 2 | $0.10 | Out of Stock | Notify Me |
| 4 | TA401014 Reflex Reflector | Reflex Reflector All except US | 1 | $9.22 | Available to order | 1 |
| 5 | KDBB0613 Plain Washer | Plain Washer | 2 | $0.10 | Out of Stock | Notify Me |
| 6 | KCGA0505 Nut, Hex Flgd | Nut, Hex Flgd | 2 | $0.10 | Out of Stock | Notify Me |
| 7 | TA181720 Cover Assembly Tail Lamp | Cover Assembly Tail Lamp All except US | 1 | $6.02 | Backorder — Mid August 2026 | 1 |
| 8 | KAEF0508 Bolt, Flanged, M5 x 0.8 | Bolt, Flanged, M5 x 0.8 | 2 | $0.60 | Out of Stock | Notify Me |
| 9 | JD113814 Grommet | Grommet | 2 | $0.60 | Out of Stock | Notify Me |
| 10 | JP181280 Collar | Collar All except US | 2 | $0.67 | Available to order | 2 |
| 11 | LBU00190 Screw, Btn Hd, M6 x 1 | Screw, Btn Hd, M6 x 1 | 2 | $0.91 | Out of Stock | Notify Me |
| 13 | TA181520 Pad | Pad All except US - Not Illustrated | 1 | $4.21 | Out of Stock | Notify Me |
