Front Forks
Parts (18)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | TA121044 Front Fork Assembly | Front Fork Assembly | 1 | $663.91 | Backorder — Late August 2026 | 1 |
| 6 | JP121068 O Ring | O Ring | 2 | $0.52 | Available to order | 2 |
| 7 | JG121012 Fork Bolt, Screw Cap | Fork Bolt, Screw Cap | 2 | $27.14 | Backorder — Late August 2026 | 2 |
| 9 | YJU34002 Oil Seal Kit | Oil Seal Kit | 2 | $34.03 | Available to order | 2 |
| 10 | LAC00230 Bolt, Skt, M8 x 1.25 | Bolt, Skt, M8 x 1.25 | 2 | $1.44 | Available to order | 2 |
| 11 | TA121048 Bracket Assembly Under | Bracket Assembly Under | 1 | $271.14 | Out of Stock | Notify Me |
| 12 | LAC00231 Bolt, Socket, M8 x 1.25 | Bolt, Socket, M8 x 1.25 | 4 | $1.44 | Available to order | 4 |
| 13 | TA113871 Clamp Hose | Clamp Hose | 1 | $1.19 | Out of Stock | Notify Me |
| 14 | LBU00050 Screw, Btn Hd, Step, M6 x1 | Screw, Btn Hd, Step, M6 x1 | 2 | $1.13 | Available to order | 2 |
| 15 | TA151035 Lock Washer | Lock Washer | 1 | $2.95 | Available to order | 1 |
| 16 | TA151011 Lock Nut | Lock Nut | 1 | $7.68 | Available to order | 1 |
| 17 | TA151036 Plain Washer | Plain Washer | 1 | $0.46 | Available to order | 1 |
| 18 | TA151012 Steering Nut | Steering Nut | 1 | $11.22 | Available to order | 1 |
| 19 | TA151013 Cap | Cap | 1 | $1.58 | Available to order | 1 |
| 20 | 36TA0199 Kit, Steering Race | Kit, Steering Race | 1 | $9.03 | Out of Stock | Notify Me |
| 21 | JG151024 Washer | Washer | 2 | $0.97 | Available to order | 2 |
| 24 | JH401031 Reflector, Reflex, Side | Reflector, Reflex, Side | 2 | $7.58 | Available to order | 2 |
| 28 | 83010501 Prolube Fork Oil | Prolube Fork Oil | 1 | $31.38 | Out of Stock | Notify Me |
