Front Mudguard
Parts (13)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 56TAT4BA Front Mudguard, Phan Blk Gloss | Front Mudguard, Phan Blk Gloss | 1 | $97.67 | Backorder — Restocking | 1 |
| 2 | 56TA9KBF Brace, Front Mudguard, LH, TA181411, Matt Phantom Blk | Brace, Front Mudguard, LH, TA181411, Matt Phantom Blk | 1 | $30.64 | Available to order | 1 |
| 3 | 56TA9LBF Brace, Front Mudguard, RH, TA181412, Matt Phantom Blk | Brace, Front Mudguard, RH, TA181412, Matt Phantom Blk | 1 | $30.64 | Available to order | 1 |
| 4 | TA181419 Fork Protector, LH | Fork Protector, LH | 1 | $44.63 | Available to order | 1 |
| 5 | TA181420 Fork Protector, RH | Fork Protector, RH | 1 | $44.63 | Available to order | 1 |
| 6 | LBU00180 Screw, Socket Step, M6 x 1 | Screw, Socket Step, M6 x 1 | 2 | $1.01 | Available to order | 2 |
| 7 | LBU00188 Screw, Btn Hd Step, M6 x 1 | Screw, Btn Hd Step, M6 x 1 | 2 | $1.13 | Available to order | 2 |
| 8 | LBU00177 Screw, Btn Hd, M5 x 0.8 | Screw, Btn Hd, M5 x 0.8 | 4 | $0.67 | Available to order | 4 |
| 9 | LDB00025 Washer, Plain | Washer, Plain | 6 | $0.10 | Available to order | 6 |
| 10 | JG171031 Nut, Clip, M5 | Nut, Clip, M5 | 4 | $0.59 | Available to order | 4 |
| 11 | LAC00189 Bolt, Socket Step, M6 x 1 | Bolt, Socket Step, M6 x 1 | 2 | $0.68 | Out of Stock | Notify Me |
| 12 | LBU00191 Screw, Button Head, M5 x 0.8 | Screw, Button Head, M5 x 0.8 | 2 | $1.19 | Out of Stock | Notify Me |
| 13 | TA181434 Brace, Fender | Brace, Fender | 1 | $8.06 | Out of Stock | Notify Me |
