Sump & Fittings
Parts (8)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1230666 Sump | Sump | 1 | $492.91 | Available to order | 1 |
| 2 | T1230444 Gasket, Sump | Gasket, Sump | 1 | $12.63 | Available to order | 1 |
| 3 | T3200148 Bolt, RHHF, M6 x 30, Slv | Bolt, RHHF, M6 x 30, Slv | 16 | $4.45 | Backorder — Early October 2026 | 16 |
| 4 | T3458989 Sump Plug, M14 x 1.5, Blk | Sump Plug, M14 x 1.5, Blk | 1 | $5.48 | Available to order | 1 |
| 5 | T3551092 Sealing Washer Multipack (25) | Sealing Washer Multipack (25) Part only available as Multipack | 1 | $27.56 | Available to order | 1 |
| 6 | T3000032 Dowel, Dia 6 x 10.8 | Dowel, Dia 6 x 10.8 | 2 | $6.45 | Out of Stock | Notify Me |
| 7 | T1230555 Sump Plate | Sump Plate | 1 | $176.81 | Available to order | 1 |
| 8 | T3330728 Screw, Pan/Hd, Tx, M5 x 16, Enc | Screw, Pan/Hd, Tx, M5 x 16, Enc | 2 | $0.97 | Available to order | 2 |
