Heated Grip Kit
Schematic
Parts (9)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9638135 Heated Grip Kit | Heated Grip Kit | 1 | $330.00 | Available to order | 1 |
| 2 | T2041199 Heated Grip, RH | Heated Grip, RH | 1 | $176.68 | Backorder — Late September 2026 | 1 |
| 3 | T2041196 Heated Grip, LH | Heated Grip, LH | 1 | $176.68 | Available to order | 1 |
| 4 | T2041468 Button Housing, H/Grip, Upper | Button Housing, H/Grip, Upper | 1 | $6.65 | Available to order | 1 |
| 5 | T2041469 Button Housing, H/Grip, Lower | Button Housing, H/Grip, Lower | 1 | $6.65 | Available to order | 1 |
| 6 | T3330247 Screw, S/Tap, Pan/Hd, M4 x 10, HD | Screw, S/Tap, Pan/Hd, M4 x 10, HD | 2 | $7.14 | Available to order | 2 |
| 7 | T3330264 Screw, S/Tap, TX, 3 x 1.35 x 12, Blk | Screw, S/Tap, TX, 3 x 1.35 x 12, Blk | 2 | $5.02 | Available to order | 2 |
| 8 | T9820073 Subharness, Heated Grips | Subharness, Heated Grips Not Illustrated | 1 | $13.35 | Available to order | 1 |
| 9 | T9631431 Plug, Bar End, Heated Grips | Plug, Bar End, Heated Grips Not Illustrated | 2 | $2.22 | Available to order | 2 |
