Rear Brake Disc and Caliper
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2023355 Disc, Rear, Dia 285 | Disc, Rear, Dia 285 | 1 | $240.24 | Available to order | 1 |
| 2 | T2020540 Caliper Assy, Front, RH | Caliper Assy, Front, RH | 1 | $674.16 | Unavailable | View Details |
| 3 | T2020077 Brake Pad Set, x 2 Pads | Brake Pad Set, x 2 Pads | 1 | $67.83 | Available to order | 1 |
| 3 | T2020194 Brake Pad, Multipack (5) | Brake Pad, Multipack (5) Multipack (5) | 1 | $236.03 | Obsolete | View Details |
| 4 | T2020505 Seal Kit, 2 Piston Caliper | Seal Kit, 2 Piston Caliper | 1 | $55.98 | Available to order | 1 |
| 5 | T2020050 Piston Set | Piston Set | 1 | $115.33 | Available to order | 1 |
| 6 | T2020014 Bleed Screw | Bleed Screw | 1 | $15.84 | Available to order | 1 |
| 7 | T2020084 Pad Pin Set, D Spec | Pad Pin Set, D Spec | 1 | $16.54 | Available to order | 1 |
| 8 | T2020086 Pad, Spring, D Spec | Pad, Spring, D Spec | 1 | $11.02 | Available to order | 1 |
| 9 | T2029090 Spares Kit, Disc Bolts | Spares Kit, Disc Bolts Kit contains 12 bolts | 1 | $70.02 | Available to order | 1 |
| 10 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 5 | $4.46 | Available to order | 5 |
| 11 | T3200601 Bolt, HHF, M8 x 40, Slv | Bolt, HHF, M8 x 40, Slv | 2 | $3.23 | Available to order | 2 |
| 12 | T2020822 Brake carrier | Brake carrier | 1 | $159.20 | Obsolete | View Details |
| 13 | 2020803-T0301 Sleeve | Sleeve | 1 | $24.45 | Out of Stock | Notify Me |
| 14 | T2020138 Torque arm | Torque arm | 1 | $33.89 | Obsolete | View Details |
| 15 | 3000050-T0301 Sleeve | Sleeve | 2 | $1.36 | Obsolete | View Details |
| 16 | T3050084 Bolt | Bolt M8 x 35mm Stainless | 2 | $2.10 | Obsolete | View Details |
| 17 | T3700020 P Clip | P Clip » 98812 | 1 | $12.22 | Out of Stock | Notify Me |
| 18 | 3700023-T0301 P Clip Replaced by T3700020 — P Clip | P Clip » 98812 | 1 | $7.80 | Unavailable | View Details |
| 19 | T3350012 Locknut, Flgd, M6, Black, Zinc | Locknut, Flgd, M6, Black, Zinc M6 | 2 | $1.21 | Available to order | 2 |
| 20 | T3450124 Cap | Cap | 2 | $5.97 | Available to order | 2 |
| 21 | T2025439 Bracket, Caliper, RH | Bracket, Caliper, RH RH | 1 | $58.76 | Backorder — Early October 2026 | 1 |
