Clutch
Parts (29)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1171805 Clutch Assembly | Clutch Assembly | 1 | $1151.35 | Out of Stock | Notify Me |
| 2 | T1171115 Clutch, Component, Outer | Clutch, Component, Outer | 1 | $719.95 | Out of Stock | Notify Me |
| 3 | T1171260 Sprocket, Aux, Drive, Assy | Sprocket, Aux, Drive, Assy | 1 | $115.33 | Available to order | 1 |
| 4 | T1171120 Bush, Clutch | Bush, Clutch | 1 | $66.22 | Backorder — Late September 2026 | 1 |
| 5 | T1170941 Thrust washer | Thrust washer | 1 | $6.06 | Out of Stock | Notify Me |
| 6 | T1171125 Centre, Clutch | Centre, Clutch | 1 | $362.63 | Available to order | 1 |
| 7 | T1171255 Seat, Judder, Spring | Seat, Judder, Spring | 1 | $13.09 | Available to order | 1 |
| 8 | T1171230 Spring, Judder | Spring, Judder | 1 | $25.33 | Available to order | 1 |
| 9 | T1171130 Plate, Clutch, 2.3mm | Plate, Clutch, 2.3mm | 6 | $23.86 | Available to order | 6 |
| 9 | T1171131 Plate, Clutch, 2.0mm | Plate, Clutch, 2.0mm | — | $23.67 | Available to order | 1 |
| 9 | T1171132 Plate, Clutch, 2.6mm | Plate, Clutch, 2.6mm | — | $23.67 | Out of Stock | Notify Me |
| 10 | T1171265 Kit, Spares, Friction, Discs | Kit, Spares, Friction, Discs | 1 | $191.84 | Out of Stock | Notify Me |
| 11 | T1171250 Disc B, Clutch, Friction | Disc B, Clutch, Friction | 1 | $29.97 | Available to order | 1 |
| 12 | T1171253 Disc A, Clutch, Friction | Disc A, Clutch, Friction | 6 | $29.97 | Available to order | 6 |
| 13 | T1171150 Plate, Clutch, Pressure | Plate, Clutch, Pressure | 1 | $252.66 | Available to order | 1 |
| 14 | T1171210 Spring, Clutch, Aftermarket | Spring, Clutch, Aftermarket | 5 | $6.81 | Out of Stock | Notify Me |
| 15 | T3201720 Bolt, Flange, M6 x 45.0 | Bolt, Flange, M6 x 45.0 | 5 | $3.61 | Available to order | 5 |
| 16 | T1179999 Washer, C, Clutch | Washer, C, Clutch | 1 | $12.14 | Available to order | 1 |
| 17 | T1171282 Washer, ID 22, OD 34 | Washer, ID 22, OD 34 | 1 | $4.95 | Available to order | 1 |
| 18 | T1170192 Nut, Clutch, M22 | Nut, Clutch, M22 | 1 | $12.75 | Available to order | 1 |
| 19 | T3500269 Circlip, Din 471, Dia. 20.0 | Circlip, Din 471, Dia. 20.0 | 1 | $3.82 | Available to order | 1 |
| 20 | T1170067 Bearing, Pressure Plate | Bearing, Pressure Plate | 1 | $33.23 | Available to order | 1 |
| 21 | T1171295 Lifter Piece, Clutch | Lifter Piece, Clutch | 1 | $43.14 | Out of Stock | Notify Me |
| 22 | T3500135 Clip-E, Din 6799, Dia. 5.0 | Clip-E, Din 6799, Dia. 5.0 | 1 | $1.73 | Available to order | 1 |
| 23 | T3551017 Washer, Plain, 7.8 x 13.0 x 1.0 | Washer, Plain, 7.8 x 13.0 x 1.0 | 1 | $1.73 | Available to order | 1 |
| 24 | T1171296 Shaft, Lifter, Clutch | Shaft, Lifter, Clutch | 1 | $73.72 | Available to order | 1 |
| 25 | T1171297 Arm, Lifter, Clutch | Arm, Lifter, Clutch | 1 | $81.20 | Available to order | 1 |
| 26 | T3205065 Bolt, HHF, Lghtd, M6 x 20, Enc | Bolt, HHF, Lghtd, M6 x 20, Enc | 1 | $5.97 | Available to order | 1 |
| 27 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 1 | $4.46 | Available to order | 1 |
