Adjustable Passenger Footboard Hardware Kit
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9758125 Adj Passgr F/Board H/Ware Kit | Adj Passgr F/Board H/Ware Kit | 1 | $158.00 | Obsolete | View Details |
| 2 | T2089010 Bracket, Mtg, Footboard, Pillion | Bracket, Mtg, Footboard, Pillion | 2 | $25.50 | Obsolete | View Details |
| 3 | T2089011 Arm, Footboard, Pillion, Adj, LH | Arm, Footboard, Pillion, Adj, LH | 1 | $21.26 | Obsolete | View Details |
| 4 | T2089012 Arm, Footboard, Pillion, Adj, RH | Arm, Footboard, Pillion, Adj, RH | 1 | $31.64 | Available to order | 1 |
| 5 | T2089013 Clevis, Footboard, Pillion, Adj | Clevis, Footboard, Pillion, Adj | 2 | $39.06 | Obsolete | View Details |
| 6 | T3500207 Circlip, Ext 8 X 0.89 | Circlip, Ext 8 X 0.89 | 2 | $2.85 | Available to order | 2 |
| 7 | T2083017 Pivot Pin | Pivot Pin | 2 | $17.77 | Available to order | 2 |
| 8 | T2081675 Detent Ball | Detent Ball | 2 | $1.91 | Available to order | 2 |
| 9 | T2081674 Spring, Detent | Spring, Detent | 2 | $6.39 | Available to order | 2 |
| 11 | T2081704 Detent Plate | Detent Plate | 4 | $10.18 | Available to order | 4 |
| 12 | T3750022 Bush, 8 x 10 x 8, Zero Tol | Bush, 8 x 10 x 8, Zero Tol | 4 | $12.55 | Available to order | 4 |
| 13 | T3300008 Rivet, Barbed, 2.1-4.3mm | Rivet, Barbed, 2.1-4.3mm | 8 | $10.18 | Available to order | 8 |
| 15 | T3051032 Screw, Cap/HD, M8 x 40, Slv | Screw, Cap/HD, M8 x 40, Slv | 2 | $1.51 | Available to order | 2 |
| 16 | T3050324 Screw, Cap/Hd, M8 x 1.25 x 35, Slv | Screw, Cap/Hd, M8 x 1.25 x 35, Slv | 2 | $4.74 | Available to order | 2 |
| 17 | T2089014 Washer, 8.6 x 12.5 x 1.6 | Washer, 8.6 x 12.5 x 1.6 | 2 | $2.68 | Obsolete | View Details |
| 18 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 2 | $2.45 | Available to order | 2 |
