Auxiliary Lamps (US)
Parts (17)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9938100 Auxiliary Lamp Kit | Auxiliary Lamp Kit | 1 | $245.00 | Obsolete | View Details |
| 2 | A9930131 Auxiliary Lamp | Auxiliary Lamp | 2 | $46.00 | Obsolete | View Details |
| 3 | A9930175 Light Bar, Assy | Light Bar, Assy | 1 | $129.00 | Obsolete | View Details |
| 4 | A9930141 Bracket, Lamp | Bracket, Lamp | 2 | $16.74 | Backorder — Mid August 2026 | 2 |
| 5 | A9930143 Indicator Bracket, LH | Indicator Bracket, LH | 1 | $11.88 | Obsolete | View Details |
| 6 | A9930144 Indicator Bracket, RH | Indicator Bracket, RH | 1 | $12.85 | Obsolete | View Details |
| 7 | A9930147 Sub Harness, Accessory Light | Sub Harness, Accessory Light | 1 | $11.55 | Obsolete | View Details |
| 9 | A9910220 Spacer, M8 | Spacer, M8 | 2 | $5.94 | Available to order | 2 |
| 10 | A9910835 Bolt, M8 x 1.25 x 35, HHF | Bolt, M8 x 1.25 x 35, HHF | 2 | $5.30 | Obsolete | View Details |
| 11 | T3350700 Nut, Flanged Domed, M8 | Nut, Flanged Domed, M8 | 2 | $2.17 | Available to order | 2 |
| 12 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 5 | $0.89 | Available to order | 5 |
| 13 | T2508033 Relay, EFI | Relay, EFI | 1 | $38.93 | Out of Stock | Notify Me |
| 14 | A9930154 Sub-Harness, Fog Lamp | Sub-Harness, Fog Lamp | 2 | $42.00 | Obsolete | View Details |
| 16 | A9910325 Spacer, 7 x 15 x 18 | Spacer, 7 x 15 x 18 | 2 | $1.95 | Obsolete | View Details |
| 17 | A9910326 Spacer, 7 x 15 x 20 | Spacer, 7 x 15 x 20 | 2 | $1.95 | Obsolete | View Details |
| 18 | A9910186 Bolt, Domed, RHHF, M6 x 35 | Bolt, Domed, RHHF, M6 x 35 | 2 | $9.18 | Available to order | 2 |
| 19 | A9930036 Bulb, 12V 35W | Bulb, 12V 35W Not illustrated | 2 | $20.52 | Available to order | 2 |
