Big Bore Performance Kit 1700cc
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9618043 Big Bore Performance Kit 1700cc | Big Bore Performance Kit 1700cc | 1 | $780.00 | Obsolete | View Details |
| 2 | T1120522 Piston, 107.1, Grade A/B | Piston, 107.1, Grade A/B | 2 | $260.52 | Available to order | 2 |
| 3 | T1120045 Gudgeon Pin | Gudgeon Pin | 2 | $48.49 | Available to order | 2 |
| 4 | T1120024 Piston Ring, 1st Compression BB | Piston Ring, 1st Compression BB | 2 | $129.27 | Available to order | 2 |
| 5 | T1120025 Piston Ring, 2nd Compression BB | Piston Ring, 2nd Compression BB | 2 | $129.27 | Available to order | 2 |
| 6 | T1120026 Piston Ring, Oil, Assy, BB | Piston Ring, Oil, Assy, BB | 2 | $24.67 | Available to order | 2 |
| 7 | T1145214 Assy, Camshaft, Ex, Decompressor, BB | Assy, Camshaft, Ex, Decompressor, BB | 1 | $404.89 | Available to order | 1 |
| 8 | T1143117 Camshaft Assy, Inlet, BB | Camshaft Assy, Inlet, BB | 1 | $510.48 | Available to order | 1 |
| 9 | T1152261 Gasket, Cyl Hd, 107.1mm, 1700 | Gasket, Cyl Hd, 107.1mm, 1700 | 1 | $82.23 | Available to order | 1 |
| 10 | T1169088 Liner, Cylinder, 107.1, Aluminium | Liner, Cylinder, 107.1, Aluminium | 2 | $273.77 | Available to order | 2 |
| 11 | T1171210 Spring, Clutch, Aftermarket | Spring, Clutch, Aftermarket | 5 | $6.39 | Backorder — Late August 2026 | 5 |
| 12 | A9730518 Cover, Embellisher, Type 2 | Cover, Embellisher, Type 2 | 1 | $29.16 | Obsolete | View Details |
| 13 | T1230069 Gasket, Sump | Gasket, Sump | 1 | $29.08 | Available to order | 1 |
| 14 | T1260660 Gasket, Clutch Cover | Gasket, Clutch Cover | 1 | $15.03 | Available to order | 1 |
| 15 | T1260661 Gasket, Alternator Cover | Gasket, Alternator Cover | 1 | $15.06 | Available to order | 1 |
| 16 | T1113102 Bolt, Con Rod | Bolt, Con Rod | 4 | $13.51 | Available to order | 4 |
| 17 | T1151105 Bolt, M12 x 110, T55 | Bolt, M12 x 110, T55 | 8 | $9.10 | Available to order | 8 |
| 18 | T3550314 Washer, M12, Hardened | Washer, M12, Hardened | 8 | $3.59 | Available to order | 8 |
| 19 | T3558989 Washer, Sealing, 14.4 x 23 x 3 | Washer, Sealing, 14.4 x 23 x 3 | 1 | $2.01 | Available to order | 1 |
| 20 | T1218001 Oil Filter, OES | Oil Filter, OES | 1 | $17.96 | Available to order | 1 |
| 21 | T1260246 Seal, Cam Cover | Seal, Cam Cover | 1 | $42.38 | Available to order | 1 |
| 22 | T1120016 Circlip, Piston | Circlip, Piston | 2 | $3.33 | Available to order | 2 |
| 23 | T1110016 Nut, Con Rod | Nut, Con Rod | 4 | $9.69 | Available to order | 4 |
| 24 | T1260309 Seal, Cam Cover, Screw, Twin Lip | Seal, Cam Cover, Screw, Twin Lip Not Illustrated | 8 | $5.82 | Available to order | 8 |
| 25 | T3350234 Locknut, Flgd, M12 x 1.25 | Locknut, Flgd, M12 x 1.25 Not Illustrated | 3 | $6.07 | Available to order | 3 |
| 26 | T3350250 Locknut, Flanged, M10 | Locknut, Flanged, M10 Not Illustrated | 1 | $4.16 | Available to order | 1 |
| 27 | T2200326 Exhaust Pipe Sealing Ring | Exhaust Pipe Sealing Ring Not Illustrated | 2 | $7.42 | Available to order | 2 |
