Passenger Backrest & Rack - Special Edition Only
Parts (8)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2301101 Passenger Backrest Sideplate, LH & RH | Passenger Backrest Sideplate, LH & RH | 1 | $387.29 | Out of Stock | Notify Me |
| 2 | T2305977 Passenger Backrest, Weldment | Passenger Backrest, Weldment | 1 | $201.51 | Backorder — Early August 2026 | 1 |
| 3 | T2305976 Sideplate Assembly, Left, Kit | Sideplate Assembly, Left, Kit | 1 | $226.22 | Out of Stock | Notify Me |
| 5 | T2305980 Washer Plate | Washer Plate | 2 | $21.97 | Available to order | 2 |
| 6 | T3205781 Bolt, HHF, Lghtd, M8 x 1.25 x 25, Slv | Bolt, HHF, Lghtd, M8 x 1.25 x 25, Slv | 4 | $1.62 | Available to order | 4 |
| 7 | T2305990 Lock | Lock Includes 2 keys | 1 | $65.63 | Available to order | 1 |
| 8 | T2305991 Lock Pawl | Lock Pawl | 1 | $17.80 | Out of Stock | Notify Me |
| 9 | T2305992 Rack, Luggage Replaced by A9750570 — Luggage Rack, Chrome | Rack, Luggage | 1 | $115.00 | Unavailable | View Details |
