Rear Brake Caliper & Disc
Parts (11)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2021616 Rear Brake Caliper Assy | Rear Brake Caliper Assy | 1 | $752.48 | Out of Stock | Notify Me |
| 2 | T2020580 Pad Pin Set | Pad Pin Set | 1 | $19.25 | Available to order | 1 |
| 3 | T2020595 Pad Spring Set | Pad Spring Set | 1 | $21.91 | Available to order | 1 |
| 4 | T2020692 Brake Pad Set, x 2 Pads | Brake Pad Set, x 2 Pads | 1 | $58.14 | Available to order | 1 |
| 5 | T2020695 Bleed Screw Set | Bleed Screw Set | 1 | $9.82 | Backorder — Early October 2026 | 1 |
| 6 | T2024966 Boot Set | Boot Set | 1 | $43.38 | Out of Stock | Notify Me |
| 7 | T2024801 Bolt, Disc, M8 x 30, Slv, Enc | Bolt, Disc, M8 x 30, Slv, Enc | 5 | $2.02 | Available to order | 5 |
| 8 | T2023334 Disc Rear Dia 310 | Disc Rear Dia 310 | 1 | $367.99 | Available to order | 1 |
| 9 | T3700016 Cable Tie, 370 Long | Cable Tie, 370 Long | 1 | $1.01 | Available to order | 1 |
| 10 | T2021946 Piston Kit | Piston Kit | 1 | $61.54 | Available to order | 1 |
| 11 | T2021947 Seal Kit | Seal Kit | 1 | $55.98 | Available to order | 1 |
