Front Forks & Yokes
Parts (52)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2045220 Stanchion Assy, LH | Stanchion Assy, LH > 438380 | 1 | $1051.66 | Backorder — Mid October 2026 | 1 |
| 1 | T2046410 Stanchion Assy LH | Stanchion Assy LH 438381 > | 1 | $1051.66 | Backorder — Mid October 2026 | 1 |
| 2 | T2045230 Stanchion Assy, RH | Stanchion Assy, RH > 438380 | 1 | $1051.66 | Out of Stock | Notify Me |
| 2 | T2046420 Stanchion Assy RH | Stanchion Assy RH 438381 > | 1 | $1051.66 | Obsolete | View Details |
| 3 | T2045228 Tube, Inner, LH | Tube, Inner, LH | 1 | $571.14 | Available to order | 1 |
| 4 | T2045210 Tuber, Inner, RH | Tuber, Inner, RH | 1 | $571.14 | Available to order | 1 |
| 5 | T2045211 Tube, Outer | Tube, Outer | 2 | $616.49 | Backorder — Early October 2026 | 2 |
| 6 | T2045229 Damper, Comp, LH | Damper, Comp, LH > 438380 | 1 | $516.75 | Out of Stock | Notify Me |
| 6 | T2045091 Damper, Comp, LH | Damper, Comp, LH 438381 > | 1 | $516.75 | Backorder — Mid October 2026 | 1 |
| 7 | T2045212 Damper, Comp, RH | Damper, Comp, RH > 438380 | 1 | $516.75 | Out of Stock | Notify Me |
| 7 | T2045092 Damper, Comp, RH | Damper, Comp, RH 438381 > | 1 | $516.75 | Out of Stock | Notify Me |
| 8 | T2042907 Sealing washer | Sealing washer | 2 | $1.21 | Available to order | 2 |
| 9 | T2046164 Capscrew, Oil Lock | Capscrew, Oil Lock | 2 | $9.69 | Available to order | 2 |
| 10 | T2045215 Spring | Spring | 2 | $104.33 | Available to order | 2 |
| 11 | T2046166 Spring Seat | Spring Seat | 2 | $19.94 | Out of Stock | Notify Me |
| 12 | T2045217 Spacer Tube, Spring | Spacer Tube, Spring | 2 | $179.41 | Available to order | 2 |
| 13 | T2046178 Slider | Slider | 2 | $13.66 | Out of Stock | Notify Me |
| 14 | T2046219 Washer, Flat | Washer, Flat | 2 | $9.21 | Available to order | 2 |
| 15 | T2046220 Spring, Adj Plate, Comp | Spring, Adj Plate, Comp | 2 | $2.14 | Available to order | 2 |
| 16 | T2046221 Top Cap | Top Cap | 2 | $68.08 | Out of Stock | Notify Me |
| 17 | T2046222 O Ring, Top Cap | O Ring, Top Cap | 2 | $3.04 | Available to order | 2 |
| 18 | T2046223 O Ring, Spring, Adj, Outer | O Ring, Spring, Adj, Outer | 2 | $2.91 | Available to order | 2 |
| 19 | T2046224 Spring Adjuster | Spring Adjuster | 2 | $30.02 | Available to order | 2 |
| 20 | T2046225 O Ring, Spring, Adj, Inner | O Ring, Spring, Adj, Inner | 2 | $2.91 | Available to order | 2 |
| 21 | T2046226 Ring Clip | Ring Clip | 2 | $1.73 | Available to order | 2 |
| 22 | T2046227 Seat, Rubber | Seat, Rubber | 2 | $6.15 | Available to order | 2 |
| 23 | T2046230 Bearing, Outer Tube | Bearing, Outer Tube > 438380 | 2 | $13.01 | Available to order | 2 |
| 23 | T2045094 Bush, Guide, Outer | Bush, Guide, Outer 438381 > | 2 | $13.01 | Available to order | 2 |
| 24 | T2046246 Seal, Spacer | Seal, Spacer | 2 | $6.37 | Backorder — Late September 2026 | 2 |
| 25 | T2046232 Oil Seal | Oil Seal | 2 | $21.77 | Available to order | 2 |
| 26 | T2046248 Stop Ring | Stop Ring | 2 | $7.28 | Available to order | 2 |
| 27 | T2041524 Kit, Dust Seals, Pair | Kit, Dust Seals, Pair Comprises of 2 x T2041542 | 1 | $44.69 | Available to order | 1 |
| 28 | T2046235 Bearing, Inner Tube | Bearing, Inner Tube > 438380 | 2 | $12.91 | Available to order | 2 |
| 28 | T2045095 Bush, Slide, Inner | Bush, Slide, Inner 438381 > | 2 | $13.01 | Available to order | 2 |
| 29 | T2040429 Pinch Bolt, S6 Fork | Pinch Bolt, S6 Fork | 2 | $6.37 | Available to order | 2 |
| 30 | T2049295 Yoke Assy, Lower | Yoke Assy, Lower | 1 | $298.54 | Obsolete | View Details |
| 31 | T3050323 Screw, Cap/Hd, M8 x 30, Slv | Screw, Cap/Hd, M8 x 30, Slv | 4 | $5.05 | Available to order | 4 |
| 32 | T2040442 Nut, Upper Yoke | Nut, Upper Yoke | 1 | $26.02 | Available to order | 1 |
| 33 | T3450250 Moss Plug | Moss Plug | 1 | $1.50 | Available to order | 1 |
| 34 | T3800091 Bearing, Sac | Bearing, Sac | 2 | $33.94 | Available to order | 2 |
| 35 | T2040301 Adjuster Nut, M30, Lower | Adjuster Nut, M30, Lower | 1 | $28.50 | Available to order | 1 |
| 36 | T2046559 Cover, Headstock Bearing | Cover, Headstock Bearing | 1 | $10.84 | Available to order | 1 |
| 37 | T2044183 Washer, Headstock | Washer, Headstock | 1 | $8.83 | Available to order | 1 |
| 38 | T2040304 Locknut, M30 | Locknut, M30 | 1 | $21.37 | Available to order | 1 |
| 39 | T3700226 Hose Guide | Hose Guide | 1 | $5.24 | Out of Stock | Notify Me |
| 40 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 1 | $1.84 | Available to order | 1 |
| 41 | T2046205 Mudguard Bracket | Mudguard Bracket | 2 | $8.37 | Available to order | 2 |
| 42 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 2 | $1.50 | Available to order | 2 |
| 43 | T3700153 Clip, Fork Stanchion | Clip, Fork Stanchion | 1 | $4.38 | Available to order | 1 |
| 44 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 2 | $4.46 | Available to order | 2 |
| 45 | T3600234 Dust Seal, Dia 55 | Dust Seal, Dia 55 | 2 | $8.88 | Available to order | 2 |
| 46 | T2701237 Kit, Reflector, Amber | Kit, Reflector, Amber Kit Contains 2 Reflectors | 1 | $28.41 | Available to order | 1 |
