Front Forks and Yokes » 43523
Parts (36)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2043200-T0301 Stanchion assembly | Stanchion assembly LH | 1 | $890.06 | Obsolete | View Details |
| 2 | 2043300-T0301 Stanchion assembly | Stanchion assembly RH | 1 | $890.06 | Obsolete | View Details |
| 3 | 2043201-T0301 Tube outer | Tube outer LH | 1 | $514.30 | Obsolete | View Details |
| 3 | 2043301-T0301 Tube outer | Tube outer RH | 1 | $514.30 | Obsolete | View Details |
| 4 | 2043050-T0301 Sliding bush | Sliding bush | 2 | $12.90 | Obsolete | View Details |
| 5 | 2040077-T0301 Washer | Washer | 2 | $4.30 | Obsolete | View Details |
| 6 | 2043052-T0301 Oil seal | Oil seal | 2 | $16.55 | Available to order | 2 |
| 7 | 2040079-T0301 Ring snap | Ring snap | 2 | $7.28 | Available to order | 2 |
| 8 | 2043054-T0301 Dust seal | Dust seal | 2 | $19.51 | Backorder — Mid October 2026 | 2 |
| 9 | 2040160-T0301 Oil lock | Oil lock | 2 | $9.60 | Available to order | 2 |
| 10 | 2040171-T0301 Bearing | Bearing | 2 | $7.60 | Available to order | 2 |
| 11 | 2043058-T0301 Cylinder assembly | Cylinder assembly | 2 | $89.20 | Obsolete | View Details |
| 12 | 2043092-T0301 Bearing | Bearing | 2 | $9.86 | Obsolete | View Details |
| 13 | 2043056-T0301 Tube assembly | Tube assembly Inner | 2 | $298.45 | Obsolete | View Details |
| 14 | 2043062-T0301 Spring | Spring | 2 | $96.85 | Obsolete | View Details |
| 15 | 2043064-T0301 Guide spring | Guide spring | 2 | $3.78 | Obsolete | View Details |
| 16 | 2043066-T0301 Spacer | Spacer | 2 | $8.87 | Out of Stock | Notify Me |
| 17 | 2043068-T0301 Cap | Cap | 2 | $72.36 | Obsolete | View Details |
| 18 | 2040170-T0301 Capscrew | Capscrew | 2 | $10.99 | Obsolete | View Details |
| 19 | 2043060-T0301 Washer sealing | Washer sealing | 2 | $7.18 | Obsolete | View Details |
| 20 | 2043130-T0301 Yoke | Yoke » 9082 Upper | 1 | $211.93 | Obsolete | View Details |
| 20 | T2040196 Yoke | Yoke 9083 » Upper | 1 | $212.80 | Obsolete | View Details |
| 21 | 2043110-T0301 Yoke | Yoke Lower | 1 | $374.64 | Obsolete | View Details |
| 22 | T3050073 Capscrew | Capscrew | 4 | $6.27 | Available to order | 4 |
| 24 | T2040061 Washer Upper Yoke | Washer Upper Yoke | 1 | $7.60 | Available to order | 1 |
| 25 | T2040060 Nut | Nut | 1 | $25.75 | Available to order | 1 |
| 26 | T2040081 O Ring, Fork Seal | O Ring, Fork Seal | 2 | $3.82 | Available to order | 2 |
| 27 | 2040225-T0301 Adjuster nut | Adjuster nut PART NO LONGER AVAILABLE » 43781 Lower | 1 | $5.88 | Obsolete | View Details |
| 28 | T2140210 Adjuster Nut, Upper | Adjuster Nut, Upper | 1 | $3.61 | Available to order | 1 |
| 29 | 2043400-T0301 Boot protective | Boot protective | 2 | $53.19 | Available to order | 2 |
| 30 | 2043410-T0301 Clip | Clip Upper - PART NO LONGER AVAILABLE | 2 | $14.00 | Obsolete | View Details |
| 31 | 2043420-T0301 Clip | Clip Lower - PART NO LONGER AVAILABLE | 2 | $6.47 | Obsolete | View Details |
| 32 | 2043470-T0301 Guide | Guide | 1 | $21.84 | Obsolete | View Details |
| 33 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 2 | $1.50 | Available to order | 2 |
| 34 | T3300090 Rivet | Rivet | 4 | $1.18 | Available to order | 4 |
| 35 | T3900405 Badge | Badge | 1 | $23.07 | Available to order | 1 |
