Rear Wheel/Final Drive
Parts (38)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2014001-T0301 Wheel assembly | Wheel assembly » 25726 | 1 | $1577.19 | Unavailable | View Details |
| 1 | T2014005 Wheel assembly | Wheel assembly 25727 » » 54710 | 1 | $1758.78 | Unavailable | View Details |
| 2 | 3800016-T0301 Ball bearing | Ball bearing | 1 | $45.12 | Available to order | 1 |
| 3 | 3800017-T0301 Ball bearing | Ball bearing | 1 | $45.12 | Available to order | 1 |
| 4 | T2012050 Spacer, Internal | Spacer, Internal | 1 | $19.87 | Obsolete | View Details |
| 5 | 3500013-T0301 Circlip, Rear Wheel | Circlip, Rear Wheel | 1 | $3.20 | Available to order | 1 |
| 6 | 3600021-T0301 Seal | Seal | 1 | $5.97 | Out of Stock | Notify Me |
| 7 | T2012211 Cush rubber | Cush rubber | 1 | $109.86 | Available to order | 1 |
| 8 | T2012129 Sprocket Carrier Assy | Sprocket Carrier Assy | 1 | $389.84 | Available to order | 1 |
| 9 | 3800018-T0301 Ball bearing | Ball bearing | 1 | $45.12 | Available to order | 1 |
| 10 | 3600022-T0301 Seal | Seal | 1 | $5.47 | Available to order | 1 |
| 11 | T2012108 Stud, Sprocket Carrier | Stud, Sprocket Carrier | 5 | $1.21 | Available to order | 5 |
| 12 | T2012092 Spacer, Internal | Spacer, Internal | 1 | $23.56 | Available to order | 1 |
| 13 | T2010048 Rear Sprocket (48T) | Rear Sprocket (48T) 48T | 1 | $53.84 | Available to order | 1 |
| 14 | T3350234 Locknut, Flgd, M12 x 1.25 | Locknut, Flgd, M12 x 1.25 | 5 | $6.46 | Available to order | 5 |
| 15 | T2010334 Chain | Chain 114 Link | 1 | $256.66 | Obsolete | View Details |
| 16 | 2010049-T0301 Drive spindle | Drive spindle | 1 | $92.37 | Backorder — Mid October 2026 | 1 |
| 17 | 2012073-T0301 Spacer lh | Spacer lh | 1 | $5.37 | Obsolete | View Details |
| 18 | 3500010-T0301 Retaining ring | Retaining ring | 2 | $2.40 | Available to order | 2 |
| 19 | T2012053 Spacer, RH, R/Wheel | Spacer, RH, R/Wheel | 1 | $23.93 | Available to order | 1 |
| 20 | 2056001-T0301 Bolt special | Bolt special » 39103 | 1 | $32.72 | Obsolete | View Details |
| 20 | T2056020 Bolt special | Bolt special 39104 » | 1 | $30.55 | Obsolete | View Details |
| 21 | T3555032 Washer, 17 x 30 x 3 | Washer, 17 x 30 x 3 M14 | 1 | $3.37 | Available to order | 1 |
| 22 | 3600023-T0301 O ring | O ring | 1 | $1.36 | Available to order | 1 |
| 23 | 2012040-T0301 Carrier, O Ring, Rear | Carrier, O Ring, Rear | 1 | $1.50 | Available to order | 1 |
| 24 | 2014040-T0301 Spoke | Spoke » 25726 RH inner | 10 | $5.64 | Obsolete | View Details |
| 24 | T2014041 Spoke | Spoke 25727 » » 54710 RH inner | 10 | $5.64 | Obsolete | View Details |
| 25 | 2014045-T0301 Spoke | Spoke » 25726 RH outer | 10 | $5.64 | Obsolete | View Details |
| 25 | T2014046 Spoke | Spoke 25727 » » 54710 RH outer | 10 | $5.64 | Obsolete | View Details |
| 26 | 2014050-T0301 Spoke | Spoke » 25726 LH inner | 10 | $5.64 | Obsolete | View Details |
| 26 | T2014051 Spoke | Spoke 25727 » » 54710 LH inner | 10 | $5.64 | Obsolete | View Details |
| 27 | 2014055-T0301 Spoke | Spoke » 25726 LH outer | 10 | $5.64 | Obsolete | View Details |
| 27 | T2014056 Spoke | Spoke 25727 » » 54710 LH outer | 10 | $5.64 | Obsolete | View Details |
| 28 | 2004350-T0301 Nipple | Nipple » 25726 | 40 | $3.61 | Available to order | 40 |
| 28 | T2004390 Nipple, Spoke | Nipple, Spoke 25727 » » 54710 | 40 | $6.81 | Available to order | 40 |
| 29 | T2014020 Wheel rim | Wheel rim » 25726 | 1 | $507.94 | Obsolete | View Details |
| 29 | T2014006 Wheel rim | Wheel rim 25727 » » 54710 | 1 | $507.94 | Obsolete | View Details |
| 30 | T2017520 Chain & Sprocket Kit, 114/48/18 | Chain & Sprocket Kit, 114/48/18 | 1 | $261.86 | Out of Stock | Notify Me |
