Front Wheel
Parts (20)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2005250 WHEEL,FRONT,19X2.5,ASSY,SIL | WHEEL,FRONT,19X2.5,ASSY,SIL | 1 | $706.90 | Obsolete | View Details |
| 2 | T2004210 Speedo drive assembly | Speedo drive assembly | 1 | $204.20 | Obsolete | View Details |
| 3 | T2004220 Sleeve | Sleeve *PART NO LONGER AVAILABLE* | 1 | $19.51 | Obsolete | View Details |
| 4 | T2001200 Speedo drive assembly | Speedo drive assembly | 1 | $192.18 | Available to order | 1 |
| 5 | T2001281 Spindle assy | Spindle assy | 1 | $83.59 | Obsolete | View Details |
| 6 | T3450499 Bung Hole, Dia 9, Black | Bung Hole, Dia 9, Black | 1 | $10.84 | Available to order | 1 |
| 7 | T3450183 Bung, Hole, Dia 7.0, Blk | Bung, Hole, Dia 7.0, Blk | 1 | $8.79 | Available to order | 1 |
| 8 | T2004296 Spacer | Spacer | 1 | $11.45 | Available to order | 1 |
| 9 | T3350155 Locknut, Thin, M16 | Locknut, Thin, M16 | 1 | $10.02 | Available to order | 1 |
| 10 | T3555032 Washer, 17 x 30 x 3 | Washer, 17 x 30 x 3 | 1 | $3.37 | Available to order | 1 |
| 11 | T3700061 Clip, Cable Double | Clip, Cable Double | 2 | $5.65 | Available to order | 2 |
| 12 | T3700082 Firtree | Firtree | 1 | $2.91 | Backorder — Mid October 2026 | 1 |
| 13 | T2006615 Valve Assy, aluminium, 90, Slv | Valve Assy, aluminium, 90, Slv | 1 | $16.64 | Available to order | 1 |
| 14 | T3800701 Bearing, Ball, 17 47 14 | Bearing, Ball, 17 47 14 | 2 | $27.13 | Available to order | 2 |
| 15 | T3600705 Oil Seal, 35 47 6 | Oil Seal, 35 47 6 | 1 | $9.69 | Available to order | 1 |
| 16 | T3500402 Circlip, Int Dia 47 | Circlip, Int Dia 47 | 1 | $0.95 | Available to order | 1 |
| 17 | T2001111 Drive Ring, Speedo | Drive Ring, Speedo *Part No Longer Available* | 1 | $18.28 | Obsolete | View Details |
| 18 | T3600706 Seal, Oil, DC 55 73 6 | Seal, Oil, DC 55 73 6 | 1 | $9.69 | Available to order | 1 |
| 19 | T2004294 SPACER,INTERNAL,FRONT WHEEL | SPACER,INTERNAL,FRONT WHEEL | 1 | $15.59 | Obsolete | View Details |
| 20 | T2006699 Wheel Weight, 5 Gram | Wheel Weight, 5 Gram | — | $8.41 | Available to order | 1 |
