Rear Brake & Disc
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2025380 Disc, Rear | Disc, Rear | 1 | $240.24 | Available to order | 1 |
| 2 | T2020608 Bolt, Disc, M8 x 18, Slv | Bolt, Disc, M8 x 18, Slv | 4 | $10.48 | Available to order | 4 |
| 3 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 4 | $2.61 | Available to order | 4 |
| 4 | T2020239 Caliper, Rear | Caliper, Rear > 660259 All Expt BR & > 639403 BR Only | 1 | $734.36 | Out of Stock | Notify Me |
| 4 | T2023052 Caliper, Rear | Caliper, Rear 660260 > All Expt BR & 639404 BR Only | 1 | $734.36 | Available to order | 1 |
| 5 | T2020966 Pad Pin Set (2 Pins) | Pad Pin Set (2 Pins) | 1 | $16.54 | Available to order | 1 |
| 6 | T2020954 Pad Spring Set | Pad Spring Set | 1 | $9.09 | Available to order | 1 |
| 7 | T2020555 Pad Set | Pad Set | 1 | $63.40 | Available to order | 1 |
| 8 | T2020050 Piston Set | Piston Set | 1 | $115.33 | Available to order | 1 |
| 9 | T2020014 Bleed Screw | Bleed Screw | 1 | $15.84 | Available to order | 1 |
| 10 | T3205687 Bolt, HHF, Lghtd, M10 x 19, Slv | Bolt, HHF, Lghtd, M10 x 19, Slv | 2 | $9.60 | Available to order | 2 |
| 11 | T2020523 Caliper Carrier, Rear | Caliper Carrier, Rear | 1 | $175.72 | Available to order | 1 |
| 12 | T3500050 Circlip, Nom Shaft 75 Dia | Circlip, Nom Shaft 75 Dia | 1 | $2.24 | Available to order | 1 |
| 13 | T2021707 Set, Sliding Seals | Set, Sliding Seals | 1 | $44.27 | Available to order | 1 |
