Side Fairings
Parts (50)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2315578 Fork Infill Moulding | Fork Infill Moulding | 1 | $43.00 | Available to order | 1 |
| 2 | T2310117 Tank Panel, End Mldg, RH | Tank Panel, End Mldg, RH | 1 | $49.57 | Available to order | 1 |
| 3 | T2310116 Tank Panel, End Mldg, LH | Tank Panel, End Mldg, LH | 1 | $49.57 | Available to order | 1 |
| 4 | T2310693-LM Rad Panel, RH, GT, Ash Grey | Rad Panel, RH, GT, Ash Grey Includes Decals Items 27 & 28 | 1 | $186.79 | Backorder — Late August 2026 | 1 |
| 4 | T2310693-NP Rad Panel, RH, GT, Satin White | Rad Panel, RH, GT, Satin White Includes Decals Items 27 & 28 | 1 | $186.79 | Backorder — Mid August 2026 | 1 |
| 5 | T2310679-LM Rad Panel, LH, GT, Ash Grey | Rad Panel, LH, GT, Ash Grey Includes Decals Items 29 & 30 | 1 | $186.79 | Out of Stock | Notify Me |
| 5 | T2310679-NP Rad Panel, LH, GT, Satin White | Rad Panel, LH, GT, Satin White Includes Decals Items 29 & 30 | 1 | $186.79 | Backorder — Mid August 2026 | 1 |
| 6 | T2315607 Mesh, Radiator Panel, Mldg, RH | Mesh, Radiator Panel, Mldg, RH | 1 | $29.24 | Available to order | 1 |
| 7 | T2315606 Mesh, Radiator Panel, Mldg, LH | Mesh, Radiator Panel, Mldg, LH | 1 | $29.88 | Available to order | 1 |
| 8 | T2310176 Tank Infill Mldg, RH | Tank Infill Mldg, RH | 1 | $40.03 | Available to order | 1 |
| 9 | T2310175 Tank Infill Mldg, LH | Tank Infill Mldg, LH | 1 | $40.03 | Available to order | 1 |
| 10 | T2310813-LM Tank Panel, RH, GT, Ash Grey | Tank Panel, RH, GT, Ash Grey Includes Decals Items 31, 32, 33, 34 | 1 | $306.86 | Out of Stock | Notify Me |
| 10 | T2310813-NP Tank Panel, RH, GT, Satin White | Tank Panel, RH, GT, Satin White Includes Decals Items 31, 32, 33, 34 | 1 | $306.86 | Out of Stock | Notify Me |
| 11 | T2311342-LM Tank Panel, LH, GT, Ash Grey | Tank Panel, LH, GT, Ash Grey Includes Decals Items 31, 35, 36, 37 | 1 | $306.86 | Out of Stock | Notify Me |
| 11 | T2311342-NP Tank Panel, LH, GT, Satin White | Tank Panel, LH, GT, Satin White Includes Decals Items 31, 35, 36, 37 | 1 | $306.86 | Out of Stock | Notify Me |
| 12 | T2310392 Infill, Radiator Mldg, RH | Infill, Radiator Mldg, RH | 1 | $96.97 | Available to order | 1 |
| 13 | T2310393 Infill, Radiator Mldg, LH | Infill, Radiator Mldg, LH | 1 | $96.97 | Available to order | 1 |
| 14 | T3020131 Grommet, 9 x 2 x 6 | Grommet, 9 x 2 x 6 | 2 | $2.00 | Available to order | 2 |
| 15 | T3330289 Screw, But/Hd, TX, M5 x 16, Slv | Screw, But/Hd, TX, M5 x 16, Slv | 2 | $1.99 | Available to order | 2 |
| 16 | T2311903 Clip, Panel Join | Clip, Panel Join | 4 | $11.91 | Available to order | 4 |
| 17 | T3330943 Screw, But/Hd, M5 x 14, Slv | Screw, But/Hd, M5 x 14, Slv | 8 | $4.92 | Available to order | 8 |
| 18 | T3350123 Nut, Captive, M5, Non-Secured | Nut, Captive, M5, Non-Secured | 4 | $2.48 | Available to order | 4 |
| 19 | T3555011 Washer, 6.5 x 20 x 2 | Washer, 6.5 x 20 x 2 | 2 | $0.97 | Available to order | 2 |
| 20 | T3555033 Washer, 8.4 x 24 x 2 | Washer, 8.4 x 24 x 2 | 4 | $2.74 | Available to order | 4 |
| 21 | T3660313 Foam Pad | Foam Pad | 2 | $0.98 | Available to order | 2 |
| 22 | T3700290 Clip, Panel, Bayonet | Clip, Panel, Bayonet | 6 | $2.37 | Available to order | 6 |
| 23 | T3701150 Plastic Rivet, Push Release | Plastic Rivet, Push Release | 2 | $0.97 | Available to order | 2 |
| 24 | T3550253 Washer, Dia 5 mm, Retaining | Washer, Dia 5 mm, Retaining | 10 | $0.97 | Available to order | 10 |
| 25 | T3331433 Screw, S/Tap, Pan TX, 4 x 11, PT | Screw, S/Tap, Pan TX, 4 x 11, PT | 10 | $1.78 | Unavailable | View Details |
| 26 | T3330960 Screw, But/Hd, M5 x 12, Slv Enc | Screw, But/Hd, M5 x 12, Slv Enc | 2 | $3.52 | Available to order | 2 |
| 27 | T2315617 Decal, Rad Panel, RH, Upper, GT, Orange | Decal, Rad Panel, RH, Upper, GT, Orange Ash Grey Panels | 1 | $30.11 | Backorder — Late August 2026 | 1 |
| 27 | T2315307 Decal, Rad Panel, RH, Upper, GT, Blue | Decal, Rad Panel, RH, Upper, GT, Blue Satin White Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 28 | T2315622 Decal, Rad Panel, RH, Lower, GT, Orange | Decal, Rad Panel, RH, Lower, GT, Orange Ash Grey Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 28 | T2315312 Decal, Rad Panel, RH, Lower, GT, Blue | Decal, Rad Panel, RH, Lower, GT, Blue Satin White Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 29 | T2315616 Decal, Rad Panel, LH, Upper, GT, Orange | Decal, Rad Panel, LH, Upper, GT, Orange Ash Grey Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 29 | T2315306 Decal, Rad Panel, LH, Upper, GT, Blue | Decal, Rad Panel, LH, Upper, GT, Blue Satin White Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 30 | T2315621 Decal, Rad Panel, LH, Lower, GT, Orange | Decal, Rad Panel, LH, Lower, GT, Orange Ash Grey Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 30 | T2315311 Decal, Rad Panel, LH, Lower, GT, Blue | Decal, Rad Panel, LH, Lower, GT, Blue Satin White Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 31 | T2310473 Decal, Tank Badge | Decal, Tank Badge Ash Grey Panels | 2 | $8.18 | Available to order | 2 |
| 31 | T2312398 Decal, Tank Badge | Decal, Tank Badge Satin White Panels | 2 | $8.56 | Out of Stock | Notify Me |
| 32 | T2316402 Decal 1, Tank, GT, RH, Ash Grey | Decal 1, Tank, GT, RH, Ash Grey Ash Grey Panels | 1 | $36.16 | Out of Stock | Notify Me |
| 32 | T2317941 Decal 1, Tank, GT, RH, Satin White | Decal 1, Tank, GT, RH, Satin White Satin White Panels | 1 | $36.16 | Out of Stock | Notify Me |
| 33 | T2317942 Decal 2, Tank, GT, RH, Sapphire Black | Decal 2, Tank, GT, RH, Sapphire Black All Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 34 | T2316404 Decal 3, Tank, GT, RH, Ash Grey | Decal 3, Tank, GT, RH, Ash Grey Ash Grey Panels | 1 | $24.10 | Backorder — Late August 2026 | 1 |
| 34 | T2317943 Decal 3, Tank, GT, RH, Satin White | Decal 3, Tank, GT, RH, Satin White Satin White Panels | 1 | $24.10 | Out of Stock | Notify Me |
| 35 | T2319611 Decal 1, Tank, GT, LH, Ash Grey | Decal 1, Tank, GT, LH, Ash Grey Ash Grey Panels | 1 | $36.16 | Out of Stock | Notify Me |
| 35 | T2317811 Decal 1, Tank, GT, LH, Satin White | Decal 1, Tank, GT, LH, Satin White Satin White Panels | 1 | $36.16 | Out of Stock | Notify Me |
| 36 | T2317812 Decal 2, Tank, GT, LH, Sapphire Black | Decal 2, Tank, GT, LH, Sapphire Black All Panels | 1 | $30.11 | Out of Stock | Notify Me |
| 37 | T2319613 Decal 3, Tank, GT, LH, Ash Grey | Decal 3, Tank, GT, LH, Ash Grey Ash Grey Panels | 1 | $24.10 | Out of Stock | Notify Me |
| 37 | T2317813 Decal 3, Tank, GT, LH, Satin White | Decal 3, Tank, GT, LH, Satin White Satin White Panels | 1 | $24.10 | Out of Stock | Notify Me |
