Ignition Switch/Seat Lock
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2500437 Lock set | Lock set Includes 2 keys | 1 | $424.06 | Obsolete | View Details |
| 2 | T3330327 Bolt, Shear, M6 x 22, Enc | Bolt, Shear, M6 x 22, Enc | 2 | $5.24 | Available to order | 2 |
| 3 | T3550436 Washer, M6, Elongated | Washer, M6, Elongated | 2 | $4.45 | Available to order | 2 |
| 4 | T3330184 Screw, C'sunk Tx, M6 x 25, Slv | Screw, C'sunk Tx, M6 x 25, Slv | 2 | $1.27 | Available to order | 2 |
| 5 | 3330415-T0301 Screw | Screw M6 x 20mm | 2 | $1.13 | Available to order | 2 |
| 6 | T2500214 Ignition Switch | Ignition Switch Includes 2 keys - PART NO LONGER AVAILABLE | 1 | $266.62 | Obsolete | View Details |
| 7 | T2500440 Key, Uncut | Key, Uncut Supplied as single - Key blank to be cut by dealer | 1 | $20.29 | Available to order | 1 |
| 7 | T2500105 Key, Cut | Key, Cut Supplied as pair - Customer must supply key number with order | 1 | $79.02 | Available to order | 1 |
| 8 | T3551283 Washer, M10, 10.5x18x1.6, Slv | Washer, M10, 10.5x18x1.6, Slv » 39513 | 2 | $2.00 | Available to order | 2 |
| 9 | T2500438 Cable | Cable | 1 | $20.96 | Obsolete | View Details |
