Front Forks and Yokes » 43509
Parts (33)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2045021 Stanchion assembly | Stanchion assembly LH | 1 | $757.71 | Obsolete | View Details |
| 2 | T2045022 Stanchion assembly | Stanchion assembly RH | 1 | $950.61 | Out of Stock | Notify Me |
| 3 | T2045040 Tube outer | Tube outer LH | 1 | $499.32 | Obsolete | View Details |
| 3 | T2045030 Tube outer | Tube outer RH | 1 | $554.50 | Backorder — Late August 2026 | 1 |
| 4 | 2040076-T0301 Sliding bush | Sliding bush | 2 | $14.73 | Available to order | 2 |
| 5 | 2040077-T0301 Washer | Washer | 2 | $3.74 | Obsolete | View Details |
| 6 | 2040078-T0301 Oil seal | Oil seal | 2 | $20.99 | Available to order | 2 |
| 7 | 2040079-T0301 Ring snap | Ring snap | 2 | $6.83 | Available to order | 2 |
| 8 | 2040080-T0301 Dust seal | Dust seal | 2 | $20.08 | Available to order | 2 |
| 9 | 2040160-T0301 Oil lock | Oil lock | 2 | $9.02 | Available to order | 2 |
| 10 | 2040171-T0301 Bearing | Bearing | 2 | $7.14 | Available to order | 2 |
| 11 | T2045042 Cylinder assembly | Cylinder assembly | 2 | $124.47 | Obsolete | View Details |
| 12 | 2040172-T0301 Bearing | Bearing | 2 | $9.88 | Available to order | 2 |
| 13 | T2045041 Tube assembly | Tube assembly Inner | 2 | $302.81 | Available to order | 2 |
| 14 | 2042205-T0301 Spring | Spring NO LONGER AVAILABLE | 2 | $85.88 | Obsolete | View Details |
| 15 | T2045043 Guide spring | Guide spring | 2 | $11.32 | Available to order | 2 |
| 16 | T2045044 Spacer | Spacer | 2 | $6.99 | Obsolete | View Details |
| 17 | T2040169 Cap, Fork | Cap, Fork | 2 | $81.75 | Available to order | 2 |
| 18 | T2045046 Capscrew, Oil Lock | Capscrew, Oil Lock | 2 | $10.63 | Available to order | 2 |
| 19 | T2045045 Washer, Sealing B | Washer, Sealing B | 2 | $1.13 | Available to order | 2 |
| 20 | T2045011 Yoke, Upper, Polished | Yoke, Upper, Polished Upper | 1 | $252.26 | Obsolete | View Details |
| 21 | T2045025 Yoke | Yoke Lower | 1 | $385.51 | Obsolete | View Details |
| 22 | T2045047 Capscrew | Capscrew M8 x 25mm | 6 | $9.41 | Available to order | 6 |
| 23 | T3450060 Cap | Cap | 1 | $1.40 | Available to order | 1 |
| 24 | T2040061 Washer Upper Yoke | Washer Upper Yoke | 1 | $7.14 | Available to order | 1 |
| 25 | T2040060 Nut | Nut | 1 | $24.83 | Available to order | 1 |
| 26 | T2040081 O Ring, Fork Seal | O Ring, Fork Seal | 2 | $3.59 | Available to order | 2 |
| 27 | 2040173-T0301 Seal kit | Seal kit | 2 | $35.44 | Available to order | 2 |
| 28 | 2040225-T0301 Adjuster nut | Adjuster nut PART NO LONGER AVAILABLE | 1 | $5.11 | Obsolete | View Details |
| 29 | T2140210 Adjuster Nut, Upper | Adjuster Nut, Upper | 1 | $3.39 | Available to order | 1 |
| 30 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 14 | $4.19 | Backorder — Mid August 2026 | 14 |
| 31 | T3450062 Plug, Plastic, Black | Plug, Plastic, Black | 2 | $1.40 | Available to order | 2 |
| 32 | T3051032 Screw, Cap/HD, M8 x 40, Slv | Screw, Cap/HD, M8 x 40, Slv | 4 | $1.51 | Available to order | 4 |
