Sumpguard
Parts (11)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9700470 Sumpguard Kit | Sumpguard Kit | 1 | $355.00 | Available to order | 1 |
| 2 | T2311294 Bracket, Sumpguard, Front, RH | Bracket, Sumpguard, Front, RH | 1 | $12.66 | Available to order | 1 |
| 3 | T2312294 Bracket, Sumpguard, Front, LH | Bracket, Sumpguard, Front, LH | 1 | $6.82 | Available to order | 1 |
| 4 | T3010707 Sleeve, Flanged, 6.4 x 10 x 6.5 | Sleeve, Flanged, 6.4 x 10 x 6.5 | 4 | $3.59 | Available to order | 4 |
| 5 | T3020076 Grommet, 11.8 x 2.5 x 10.0 | Grommet, 11.8 x 2.5 x 10.0 | 4 | $1.03 | Backorder — Mid August 2026 | 4 |
| 6 | T3010702 Flanged Sleeve, 6.4 x 10 x 8.5 | Flanged Sleeve, 6.4 x 10 x 8.5 | 2 | $5.78 | Available to order | 2 |
| 7 | T3021100 Grommet, Dia 13 x 1.8 | Grommet, Dia 13 x 1.8 | 2 | $2.85 | Available to order | 2 |
| 8 | T3350111 Nut, Captive, M6 | Nut, Captive, M6 | 2 | $4.92 | Backorder — Early August 2026 | 2 |
| 9 | T3550634 Washer, 6.4 x 16 x 2 | Washer, 6.4 x 16 x 2 | 4 | $1.72 | Out of Stock | Notify Me |
| 10 | T3200190 Bolt, RHHF, M6 x 25, Slv | Bolt, RHHF, M6 x 25, Slv | 6 | $2.63 | Available to order | 6 |
| 11 | T2311293 Sumpguard | Sumpguard | 1 | $288.88 | Available to order | 1 |
