Camshaft and Drive
Parts (64)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 1140430-T0301 Camshaft exhaust | Camshaft exhaust | 1 | $382.84 | Obsolete | View Details |
| 2 | 1140410-T0301 Camshaft inlet | Camshaft inlet | 1 | $382.84 | Obsolete | View Details |
| 3 | T1141127 Sprocket, Camshaft | Sprocket, Camshaft | 2 | $104.56 | Available to order | 2 |
| 4 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 4 | $1.40 | Available to order | 4 |
| 5 | T1130065 Bucket, Tappet | Bucket, Tappet No longer graded | 12 | $15.88 | Available to order | 12 |
| 6 | 1140211-T0301 Chain camshaft drive | Chain camshaft drive 146 Link | 1 | $148.31 | Available to order | 1 |
| 7 | T1140004 Blade | Blade | 1 | $40.87 | Available to order | 1 |
| 8 | 1140040-T0301 Blade, Tensioner, Cam Chain | Blade, Tensioner, Cam Chain | 1 | $121.69 | Available to order | 1 |
| 9 | 1140110-T0301 Tensioner tube | Tensioner tube | 1 | $4.59 | Obsolete | View Details |
| 10 | T3550276 Washer, M8, Hardened | Washer, M8, Hardened | 2 | $0.97 | Backorder — Late September 2026 | 2 |
| 11 | T3200090 Bolt, RHHF, M8 x 30, Slv, Enc | Bolt, RHHF, M8 x 30, Slv, Enc | 1 | $2.10 | Available to order | 1 |
| 12 | T1140180 Tensioner Assy, Silver | Tensioner Assy, Silver | 1 | $184.39 | Available to order | 1 |
| 13 | T1140187 Gasket, Tensioner | Gasket, Tensioner | 1 | $2.81 | Available to order | 1 |
| 14 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv | 2 | $4.55 | Available to order | 2 |
| 15 | 1140190-T0301 Top pad | Top pad | 1 | $31.38 | Obsolete | View Details |
| 16 | T1130200 Shim Tappet, 2.000mm | Shim Tappet, 2.000mm 2.000mm | — | $10.18 | Available to order | 1 |
| 16 | T1130202 Shim Tappet, 2.025mm | Shim Tappet, 2.025mm 2.025mm | — | $8.18 | Available to order | 1 |
| 16 | T1130205 Shim, Tappet, 2.050 | Shim, Tappet, 2.050 2.05mm | — | $10.18 | Available to order | 1 |
| 16 | T1130207 Shim Tappet, 2.075mm | Shim Tappet, 2.075mm 2.075mm | — | $8.18 | Available to order | 1 |
| 16 | T1130210 Shim, Tappet, 2.100 | Shim, Tappet, 2.100 2.10mm | — | $10.18 | Available to order | 1 |
| 16 | T1130212 Shim Tappet, 2.125mm | Shim Tappet, 2.125mm 2.125mm | — | $10.18 | Available to order | 1 |
| 16 | T1130215 Shim, Tappet, 2.150 | Shim, Tappet, 2.150 2.15mm | — | $10.18 | Available to order | 1 |
| 16 | T1130217 Shim Tappet, 2.175mm | Shim Tappet, 2.175mm 2.175mm | — | $8.18 | Available to order | 1 |
| 16 | T1130220 Shim, Tappet, 2.200 | Shim, Tappet, 2.200 2.20mm | — | $10.18 | Available to order | 1 |
| 16 | T1130222 Shim Tappet, 2.225mm | Shim Tappet, 2.225mm 2.225mm | — | $8.18 | Available to order | 1 |
| 16 | T1130225 Shim, Tappet, 2.250 | Shim, Tappet, 2.250 2.25mm | — | $10.18 | Available to order | 1 |
| 16 | T1130227 Shim Tappet, 2.275mm | Shim Tappet, 2.275mm 2.275mm | — | $5.14 | Available to order | 1 |
| 16 | T1130230 Shim, Tappet, 2.300 | Shim, Tappet, 2.300 2.30mm | — | $10.18 | Available to order | 1 |
| 16 | T1130232 Shim Tappet, 2.325mm | Shim Tappet, 2.325mm 2.325mm | — | $10.01 | Available to order | 1 |
| 16 | T1130235 Shim, Tappet, 2.350 | Shim, Tappet, 2.350 2.35mm | — | $10.18 | Available to order | 1 |
| 16 | T1130237 Shim Tappet, 2.375mm | Shim Tappet, 2.375mm 2.375mm | — | $8.18 | Available to order | 1 |
| 16 | T1130240 Shim, Tappet, 2.400 | Shim, Tappet, 2.400 2.40mm | — | $10.18 | Available to order | 1 |
| 16 | T1130242 Shim Tappet, 2.425mm | Shim Tappet, 2.425mm 2.425mm | — | $10.18 | Available to order | 1 |
| 16 | T1130245 Shim, Tappet, 2.450 | Shim, Tappet, 2.450 2.45mm | — | $10.18 | Available to order | 1 |
| 16 | T1130247 Shim Tappet, 2.475mm | Shim Tappet, 2.475mm 2.475mm | — | $10.18 | Available to order | 1 |
| 16 | T1130250 Shim, Tappet, 2.500 | Shim, Tappet, 2.500 2.50mm | — | $10.18 | Available to order | 1 |
| 16 | T1130252 Shim Tappet, 2.525mm | Shim Tappet, 2.525mm 2.525mm | — | $10.18 | Available to order | 1 |
| 16 | T1130255 Shim, Tappet, 2.550 | Shim, Tappet, 2.550 2.55mm | — | $10.18 | Available to order | 1 |
| 16 | T1130257 Shim Tappet, 2.575mm | Shim Tappet, 2.575mm 2.575mm | — | $8.18 | Available to order | 1 |
| 16 | T1130260 Shim, Tappet, 2.600 | Shim, Tappet, 2.600 2.60mm | — | $10.18 | Available to order | 1 |
| 16 | T1130262 Shim Tappet, 2.625mm | Shim Tappet, 2.625mm 2.625mm | — | $10.18 | Available to order | 1 |
| 16 | T1130265 Shim, Tappet, 2.650 | Shim, Tappet, 2.650 2.65mm | — | $10.18 | Available to order | 1 |
| 16 | T1130267 Shim Tappet, 2.675mm | Shim Tappet, 2.675mm 2.675mm | — | $8.18 | Available to order | 1 |
| 16 | T1130270 Shim, Tappet, 2.700 | Shim, Tappet, 2.700 2.70mm | — | $10.18 | Available to order | 1 |
| 16 | T1130272 Shim Tappet, 2.725mm | Shim Tappet, 2.725mm 2.725mm | — | $10.18 | Available to order | 1 |
| 16 | T1130275 Shim, Tappet, 2.750 | Shim, Tappet, 2.750 2.75mm | — | $10.18 | Available to order | 1 |
| 16 | T1130277 Shim Tappet, 2.775mm | Shim Tappet, 2.775mm 2.775mm | — | $8.18 | Available to order | 1 |
| 16 | T1130280 Shim, Tappet, 2.800 | Shim, Tappet, 2.800 2.80mm | — | $10.18 | Available to order | 1 |
| 16 | T1130282 Shim Tappet, 2.825mm | Shim Tappet, 2.825mm 2.825mm | — | $8.18 | Available to order | 1 |
| 16 | T1130285 Shim, Tappet, 2.850 | Shim, Tappet, 2.850 2.85mm | — | $10.18 | Available to order | 1 |
| 16 | T1130287 Shim Tappet, 2.875mm | Shim Tappet, 2.875mm 2.875mm | — | $8.18 | Available to order | 1 |
| 16 | T1130290 Shim, Tappet, 2.900 | Shim, Tappet, 2.900 2.90mm | — | $10.18 | Available to order | 1 |
| 16 | T1130292 Shim Tappet, 2.925mm | Shim Tappet, 2.925mm 2.925mm | — | $10.18 | Available to order | 1 |
| 16 | T1130295 Shim, Tappet, 2.950 | Shim, Tappet, 2.950 2.95mm | — | $10.18 | Available to order | 1 |
| 16 | T1130297 Shim Tappet, 2.975mm | Shim Tappet, 2.975mm 2.975mm | — | $10.18 | Available to order | 1 |
| 16 | T1130300 Shim Tappet, 3.000mm | Shim Tappet, 3.000mm 3.00mm | — | $10.18 | Available to order | 1 |
| 16 | T1130302 Shim Tappet, 3.025mm | Shim Tappet, 3.025mm 3.025mm | — | $10.18 | Available to order | 1 |
| 16 | T1130305 Shim, Tappet, 3.050 | Shim, Tappet, 3.050 3.05mm | — | $10.18 | Available to order | 1 |
| 16 | T1130307 Shim Tappet, 3.075mm | Shim Tappet, 3.075mm 3.075mm | — | $10.18 | Available to order | 1 |
| 16 | T1130310 Shim, Tappet, 3.100 | Shim, Tappet, 3.100 3.10mm | — | $10.18 | Available to order | 1 |
| 16 | T1130312 Shim Tappet, 3.125mm | Shim Tappet, 3.125mm 3.125mm | — | $10.18 | Available to order | 1 |
| 16 | T1130315 Shim, Tappet, 3.150 | Shim, Tappet, 3.150 3.15mm | — | $10.18 | Available to order | 1 |
| 16 | T1130317 Shim Tappet, 3.175mm | Shim Tappet, 3.175mm 3.175mm | — | $10.18 | Available to order | 1 |
| 16 | T1130320 Shim, Tappet, 3.200 | Shim, Tappet, 3.200 3.20mm | — | $10.18 | Available to order | 1 |
