Mudguard Pad Kit
Parts (13)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9950035 Mudguard pad kit | Mudguard pad kit | 1 | $168.00 | Out of Stock | Notify Me |
| 2 | A2300299 Pad | Pad | 1 | $116.00 | Obsolete | View Details |
| 3 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 1 | $2.45 | Available to order | 1 |
| 4 | A3550038 Washer | Washer | 1 | $0.25 | Obsolete | View Details |
| 5 | 3000080-T0301 Clip | Clip * Part No Longer Available * | 1 | $0.70 | Obsolete | View Details |
| 6 | A9701110 Footrest kit | Footrest kit Comprises items 7-13 | 1 | $54.00 | Obsolete | View Details |
| 7 | T2080233 Kit, Footrest Assy, LH & RH | Kit, Footrest Assy, LH & RH LH | 1 | $112.13 | Backorder — Early August 2026 | 1 |
| 8 | T2080234 Kit, Footrest Assy, LH & RH | Kit, Footrest Assy, LH & RH RH | 1 | $112.13 | Available to order | 1 |
| 9 | T2070826 Clevis assy | Clevis assy | 2 | $15.95 | Available to order | 2 |
| 10 | T2080721 Pivot Pin, Footrest | Pivot Pin, Footrest | 2 | $6.45 | Available to order | 2 |
| 11 | T3500210 Circlip, Ext, 8 x 1 | Circlip, Ext, 8 x 1 | 2 | $2.14 | Available to order | 2 |
| 12 | T2080724 Spring, Footrest (Rear) | Spring, Footrest (Rear) | 2 | $2.10 | Available to order | 2 |
| 13 | T2080725 Detent Ball | Detent Ball | 2 | $1.72 | Available to order | 2 |
