Instruments
Parts (37)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2501163 Instrument Assy, MPH | Instrument Assy, MPH MPH | 1 | $995.75 | Obsolete | View Details |
| 1 | T2501168 Instrument Assy, KPH | Instrument Assy, KPH KPH | 1 | $867.60 | Obsolete | View Details |
| 2 | T2502089 Bulb, T10 12v 1.7w | Bulb, T10 12v 1.7w 2.0 watt Speedo, Tacho gauges | 4 | $2.74 | Available to order | 4 |
| 3 | T2502090 Bulb, T6.5 12v 1.7w | Bulb, T6.5 12v 1.7w 1.2 watt Warning lamps | 6 | $5.60 | Unavailable | View Details |
| 4 | T3550265 Washer, M5, C'sunk | Washer, M5, C'sunk | 2 | $4.19 | Available to order | 2 |
| 5 | T3330643 Screw, M5 x 30, CSK SKT, Patch | Screw, M5 x 30, CSK SKT, Patch | 2 | $2.00 | Available to order | 2 |
| 6 | T2502106 Speedometer mph | Speedometer mph » 86435 - VIN required on order | 1 | $313.32 | Obsolete | View Details |
| 6 | T2501174 Speedometer mph | Speedometer mph 86536 » | 1 | $313.32 | Obsolete | View Details |
| 6 | T2502107 Speedometer kph | Speedometer kph PART NO LONGER AVAILABLE - » 89489 | 1 | $333.63 | Obsolete | View Details |
| 6 | T2501175 Speedometer kph | Speedometer kph 89490 » | 1 | $319.58 | Obsolete | View Details |
| 7 | T2501173 Tachometer | Tachometer 86436 », MPH 89490 », KPH | 1 | $337.39 | Obsolete | View Details |
| 8 | T2501170 Plate | Plate Warning lamps » 86435, MPH » 89489, KPH | 1 | $69.37 | Available to order | 1 |
| 9 | T2501187 Screw | Screw | 2 | $1.06 | Obsolete | View Details |
| 10 | T2502108 Mounting plate | Mounting plate » 86435, MPH » 89489, KPH | 1 | $31.10 | Obsolete | View Details |
| 10 | T2501178 Mounting plate | Mounting plate 86436 », MPH 89490 », KPH - PART NO LONGER AVAILABLE | 1 | $34.10 | Obsolete | View Details |
| 11 | T2502092 Housing speedo | Housing speedo » 86435, MPH » 89489, KPH | 1 | $122.31 | Obsolete | View Details |
| 11 | T2501185 Housing speedo | Housing speedo 86436 », MPH 89490 », KPH | 1 | $163.49 | Available to order | 1 |
| 12 | T2502093 Housing tacho | Housing tacho » 86435, MPH » 89489, KPH | 1 | $122.37 | Obsolete | View Details |
| 12 | T2501186 Housing tacho | Housing tacho 86436 », MPH 89490 », KPH | 1 | $163.49 | Available to order | 1 |
| 13 | T2501189 Domed nut | Domed nut | 2 | $2.25 | Backorder — Late August 2026 | 2 |
| 14 | T2501188 Washer | Washer | 2 | $1.27 | Available to order | 2 |
| 15 | T2502046 Harness | Harness » 86435, MPH » 89489, KPH | 1 | $165.15 | Obsolete | View Details |
| 15 | T2501179 Harness | Harness 86436 », MPH 89490 », KPH | 1 | $173.41 | Obsolete | View Details |
| 16 | T2501172 Knob, Trip, Speedometer | Knob, Trip, Speedometer 89490 > | 1 | $9.49 | Available to order | 1 |
| 17 | T2501205 Screw, Reset Knob | Screw, Reset Knob | 1 | $1.40 | Available to order | 1 |
| 18 | T2501184 Cover housing | Cover housing PART NO LONGER AVAILABLE - Warning lamps » 86435, MPH » 89489, KPH | 1 | $9.45 | Obsolete | View Details |
| 19 | T2501171 Screw | Screw | 3 | $1.51 | Available to order | 3 |
| 20 | T3930090 Label | Label Unleaded fuel US Cal ONLY | 1 | $9.47 | Obsolete | View Details |
| 21 | T2502084 Housing instruments | Housing instruments » 86435, MPH » 89489, KPH | 1 | $30.57 | Obsolete | View Details |
| 21 | T2501183 Housing | Housing 86436 », MPH 89490 », KPH | 1 | $30.57 | Obsolete | View Details |
| 22 | T2502081 Lens warning light | Lens warning light » 86435, MPH » 89489, KPH - PART NO LONGER AVAILABLE | 1 | $10.80 | Obsolete | View Details |
| 22 | T2501182 Lens warning light | Lens warning light 86436 », MPH 89490 », KPH | 1 | $12.83 | Out of Stock | Notify Me |
| 23 | T2502082 Gasket | Gasket » 86435, MPH » 89489, KPH | 1 | $3.17 | Obsolete | View Details |
| 23 | T2501181 Gasket | Gasket 86436 », MPH 89490 », KPH | 1 | $3.17 | Obsolete | View Details |
| 24 | T2502102 Cover instruments | Cover instruments » 86435, MPH » 89489, KPH | 1 | $7.38 | Obsolete | View Details |
| 24 | T2501180 Cover instruments | Cover instruments 86436 », MPH 89490 », KPH | 1 | $12.43 | Obsolete | View Details |
| 25 | T2501176 Gasket | Gasket » 86435, MPH » 89489, KPH | 2 | $11.12 | Available to order | 2 |
