Headlight/Mountings
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2700080-T0301 Screw csk head | Screw csk head M4 x 45mm | 1 | $2.98 | Obsolete | View Details |
| 2 | T2700081 Screw, C'sunk, Phil, M5 x .08 x 16 | Screw, C'sunk, Phil, M5 x .08 x 16 M5 x 14mm | 2 | $1.27 | Available to order | 2 |
| 3 | 2700082-T0301 Shouldered bolt | Shouldered bolt M5 x 12mm | 2 | $3.77 | Available to order | 2 |
| 4 | T2700493 Nut & Washer Assy, M5, Slv | Nut & Washer Assy, M5, Slv | 2 | $1.79 | Available to order | 2 |
| 5 | T2700084 Nut, Square, M4 | Nut, Square, M4 M4 | 1 | $3.77 | Available to order | 1 |
| 6 | 2700085-T0301 Washer | Washer M5 | 2 | $3.77 | Backorder — Late August 2026 | 2 |
| 7 | T2700004 Rim, Headlight | Rim, Headlight | 1 | $84.58 | Available to order | 1 |
| 8 | T2701186 Screw, Pan/HD, M3 x 12 | Screw, Pan/HD, M3 x 12 | 2 | $1.13 | Available to order | 2 |
| 9 | T2700418 Rim, Headlight Retainer | Rim, Headlight Retainer | 1 | $84.58 | Available to order | 1 |
| 10 | T2700722 Spring | Spring | 1 | $4.19 | Available to order | 1 |
| 11 | T3551088 Washer, 4.25 x 8 x 0.8 | Washer, 4.25 x 8 x 0.8 | 1 | $0.97 | Available to order | 1 |
| 12 | 2700012-T0301 Mounting ring | Mounting ring | 1 | $81.75 | Available to order | 1 |
| 13 | T2700191 Bowl | Bowl | 1 | $129.27 | Available to order | 1 |
| 14 | T3020351 Grommet, 56 x 0.75 x 52 | Grommet, 56 x 0.75 x 52 | 1 | $3.17 | Available to order | 1 |
| 15 | T2701010 Headlight Assy, LH | Headlight Assy, LH UK, NZ, AU, JP, ZA, CY, HK, MY, SG LH dip | 1 | $268.77 | Available to order | 1 |
| 15 | T2701011 Headlight Assy, RH | Headlight Assy, RH ES,DE,IT,PT,CH,GR,AR,BR,SE. RH dip | 1 | $268.77 | Available to order | 1 |
| 15 | T2701009 Headlight Assy, Sym | Headlight Assy, Sym CA,US. | 1 | $279.90 | Available to order | 1 |
| 16 | T2700001 Bulb, H4 60/55W, 12V, Type 1, Clear | Bulb, H4 60/55W, 12V, Type 1, Clear | 1 | $17.69 | Available to order | 1 |
| 17 | T2700210 Bulb, Parking Lamp, 12V 4W | Bulb, Parking Lamp, 12V 4W | 1 | $4.12 | Available to order | 1 |
| 18 | T2701017 Subharness, Headlight | Subharness, Headlight Outer cover not supplied | 1 | $26.56 | Available to order | 1 |
| 19 | T2700380 Mounting tube | Mounting tube ** Part No Longer Available ** | 2 | $63.40 | Obsolete | View Details |
| 20 | T3020010 Grommet, Mounting Tube | Grommet, Mounting Tube | 4 | $3.77 | Out of Stock | Notify Me |
| 21 | T2700375 Bracket lh | Bracket lh | 1 | $84.58 | Available to order | 1 |
| 22 | T2700376 Bracket rh | Bracket rh | 1 | $84.58 | Available to order | 1 |
| 23 | T3010702 Flanged Sleeve, 6.4 x 10 x 8.5 | Flanged Sleeve, 6.4 x 10 x 8.5 | 4 | $5.78 | Available to order | 4 |
| 24 | T3350044 Domenut, Locking, M6 | Domenut, Locking, M6 | 4 | $2.22 | Available to order | 4 |
| 25 | T3330620 Bolt domed | Bolt domed | 2 | $9.49 | Available to order | 2 |
| 26 | T3550277 Washer, M8 | Washer, M8 | 2 | $1.06 | Available to order | 2 |
| 27 | T2700340 Grommet | Grommet | 4 | $6.73 | Available to order | 4 |
| 28 | T3555004 Washer, 6.4 x 14 x 1.6 | Washer, 6.4 x 14 x 1.6 | 3 | $1.40 | Available to order | 3 |
| 29 | T3660114 Foam seal | Foam seal Use with T2700703 | 1 | $5.02 | Available to order | 1 |
