Electrical Equipment
Parts (51)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2501116 Kit, ABS Harness & Gear Sensor | Kit, ABS Harness & Gear Sensor > 678236 - All Except BR | 1 | $915.65 | Available to order | 1 |
| 1 | T2501095 Harness, Main, ABS | Harness, Main, ABS 678237 > All Except BR | 1 | $797.81 | Available to order | 1 |
| 2 | T2501310 Fuse, Mini, 10A | Fuse, Mini, 10A | 5 | $5.05 | Available to order | 5 |
| 3 | T2501315 Fuse, Mini, 15A | Fuse, Mini, 15A | 4 | $5.05 | Available to order | 4 |
| 4 | T2501320 Fuse, Mini, 20A | Fuse, Mini, 20A | 3 | $5.05 | Available to order | 3 |
| 5 | T2505035 Fuse 40 amp | Fuse 40 amp | 1 | $1.21 | Available to order | 1 |
| 6 | T3350003 Locknut, Flanged, M6 x 1 | Locknut, Flanged, M6 x 1 | 1 | $0.71 | Available to order | 1 |
| 7 | T2507727 Relay, Normally Open | Relay, Normally Open | 6 | $20.87 | Available to order | 6 |
| 8 | T2507728 Relay, Changeover | Relay, Changeover | 1 | $19.19 | Available to order | 1 |
| 9 | T2504061 Immobiliser ECU, with RF 434 | Immobiliser ECU, with RF 434 All Markets Excpt JP | 1 | $1495.89 | Available to order | 1 |
| 9 | T2504071 Immobiliser ECU, with RF 315 | Immobiliser ECU, with RF 315 JP Only | 1 | $1495.89 | Available to order | 1 |
| 10 | T3332464 Screw, S/Tap, Tx, 5 x 25 | Screw, S/Tap, Tx, 5 x 25 | 2 | $2.31 | Available to order | 2 |
| 11 | T1310008 Starter Solenoid Assy | Starter Solenoid Assy | 1 | $71.82 | Available to order | 1 |
| 13 | T2502450 Battery | Battery All Markets Except BR/EF/ER/GR | 1 | $144.37 | Available to order | 1 |
| 13 | T2504604 Spares Kit, Battery | Spares Kit, Battery BR Only | 1 | $155.31 | Backorder — Mid October 2026 | 1 |
| 13 | T2506723 Kit, Battery, EU, YTX20L-BS | Kit, Battery, EU, YTX20L-BS EF/ER/GR Markets Only | 1 | $155.24 | Out of Stock | Notify Me |
| 13 | T2502376 Battery Multipack (10) | Battery Multipack (10) All Markets Except BR (10 x T2502450) | 1 | $1483.76 | Out of Stock | Notify Me |
| 14 | T2501750 Battery Strap | Battery Strap | 1 | $10.02 | Available to order | 1 |
| 15 | T2500759 Horn Assy, Low Tone | Horn Assy, Low Tone | 1 | $67.15 | Available to order | 1 |
| 16 | T3201228 Bolt, HHF, M8 x 14, Slv | Bolt, HHF, M8 x 14, Slv | 1 | $2.91 | Available to order | 1 |
| 17 | T2502405 Switch, Fall Detection | Switch, Fall Detection | 1 | $77.49 | Available to order | 1 |
| 18 | T3551066 Washer, 4.3 x 12.0 x 1.0 | Washer, 4.3 x 12.0 x 1.0 | 2 | $1.73 | Out of Stock | Notify Me |
| 19 | T3330390 Screw, H/Hd, M4 x 25, Slv, Enc | Screw, H/Hd, M4 x 25, Slv, Enc | 2 | $2.91 | Available to order | 2 |
| 20 | T2503572 Starter Lead | Starter Lead | 1 | $75.58 | Available to order | 1 |
| 21 | T2503573 Battery Lead, Positive | Battery Lead, Positive | 1 | $38.50 | Available to order | 1 |
| 22 | T2503574 Earth Lead | Earth Lead | 1 | $10.95 | Available to order | 1 |
| 23 | T1290975 Air Pressure Sensor | Air Pressure Sensor | 1 | $139.14 | Available to order | 1 |
| 24 | T3200190 Bolt, RHHF, M6 x 25, Slv | Bolt, RHHF, M6 x 25, Slv | 1 | $2.79 | Available to order | 1 |
| 25 | T1290088 Sensor, Air Temperature | Sensor, Air Temperature | 1 | $63.55 | Available to order | 1 |
| 26 | T3050342 Screw, Cap/Hd, M5 x 16, Slv | Screw, Cap/Hd, M5 x 16, Slv | 1 | $3.04 | Available to order | 1 |
| 27 | T2505075 Socket, Auxillary Power | Socket, Auxillary Power | 1 | $58.76 | Available to order | 1 |
| 28 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 1 | $1.84 | Available to order | 1 |
| 29 | T2503600 Cable, Tidy, Sump | Cable, Tidy, Sump | 1 | $9.82 | Backorder — Mid October 2026 | 1 |
| 31 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 2 | $1.50 | Available to order | 2 |
| 32 | T3701170 Plastic Rivet, Screw Type | Plastic Rivet, Screw Type | 1 | $1.29 | Available to order | 1 |
| 33 | T3451400 Plug, Dia 17.5mm | Plug, Dia 17.5mm | 1 | $2.24 | Available to order | 1 |
| 34 | T2503501 ECU Bracket | ECU Bracket | 1 | $39.71 | Available to order | 1 |
| 35 | T3660077 Trim, Cut Length, 70mm | Trim, Cut Length, 70mm | 1 | $5.16 | Available to order | 1 |
| 37 | T3555026 Washer, 6.4 x 18 x 1.6 | Washer, 6.4 x 18 x 1.6 | 2 | $1.29 | Available to order | 2 |
| 38 | T3350088 Domenut, Locking, M6 | Domenut, Locking, M6 | 1 | $1.91 | Available to order | 1 |
| 39 | T3700192 P Clip, ID 8mm | P Clip, ID 8mm | 1 | $11.54 | Available to order | 1 |
| 41 | T3700061 Clip, Cable Double | Clip, Cable Double | 1 | $5.65 | Available to order | 1 |
| 42 | T2503577 Engine Subharness | Engine Subharness | 1 | $95.18 | Available to order | 1 |
| 43 | T2501069 Moulding, Crankcase Tidy | Moulding, Crankcase Tidy | 1 | $11.21 | Backorder — Mid October 2026 | 1 |
| 44 | T3205064 Bolt, RHHF, Domed, S/S, M6 x 16, Enc | Bolt, RHHF, Domed, S/S, M6 x 16, Enc | 1 | $4.27 | Available to order | 1 |
| 45 | T2500702 Solenoid Bracket | Solenoid Bracket | 1 | $7.08 | Out of Stock | Notify Me |
| 46 | T2503579 Bracket, Sub-Harness Connector | Bracket, Sub-Harness Connector | 1 | $16.84 | Backorder — Mid October 2026 | 1 |
| 48 | T2503502 Anti-Tamper Bracket | Anti-Tamper Bracket | 1 | $10.02 | Out of Stock | Notify Me |
| 49 | T3010062 Flanged Sleeve, M6 x 7.8 x 2.85 | Flanged Sleeve, M6 x 7.8 x 2.85 | 2 | $7.60 | Available to order | 2 |
| 51 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 2 | $0.95 | Available to order | 2 |
| 52 | T2503436 Auxiliary Fly Lead, Japan | Auxiliary Fly Lead, Japan JP Only - 682880 > | 1 | $26.29 | Available to order | 1 |
