Rear Swingarm
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2056502 Swingarm Spares Assembly | Swingarm Spares Assembly PART NO LONGER AVAILABLE - Includes items 3, 12 & 14 | 1 | $1230.77 | Obsolete | View Details |
| 2 | T2050666 Pivot Pin, M30 | Pivot Pin, M30 | 1 | $10.61 | Out of Stock | Notify Me |
| 3 | T3800062 Bearing/Seal, Taper Roller,174013 | Bearing/Seal, Taper Roller,174013 | 2 | $68.08 | Available to order | 2 |
| 4 | T2050321 Pivot Pin, M30 x 1.5, Hdless | Pivot Pin, M30 x 1.5, Hdless | 1 | $10.61 | Available to order | 1 |
| 5 | T2057048 Locking Ring, M30 x 1.5 | Locking Ring, M30 x 1.5 | 1 | $17.27 | Out of Stock | Notify Me |
| 6 | T2050502 Pin, Pivot, M36, Hdless | Pin, Pivot, M36, Hdless | 1 | $10.61 | Available to order | 1 |
| 7 | T2050910 Lock Ring, M36 | Lock Ring, M36 | 1 | $24.57 | Available to order | 1 |
| 8 | T2050135 Rubber Boot, Oval | Rubber Boot, Oval | 1 | $25.51 | Available to order | 1 |
| 9 | T3701050 Band Clamp, 55mm | Band Clamp, 55mm | 1 | $10.61 | Backorder — Early October 2026 | 1 |
| 10 | T3701060 Band Clamp, 78mm | Band Clamp, 78mm | 1 | $10.95 | Available to order | 1 |
| 11 | T2050185 Rubber Boot, Rear | Rubber Boot, Rear | 1 | $5.35 | Available to order | 1 |
| 12 | T3800199 Bearing, Needle Roller, 20 x 26 x 20 | Bearing, Needle Roller, 20 x 26 x 20 | 2 | $17.10 | Available to order | 2 |
| 13 | T2057399 Sleeve, Ground Steel, 90mm | Sleeve, Ground Steel, 90mm | 1 | $40.22 | Out of Stock | Notify Me |
| 14 | T3600178 Seal, 20 x 26 x 4 | Seal, 20 x 26 x 4 | 2 | $8.21 | Available to order | 2 |
| 15 | T2051013 Cover, Pivot Pin, Swingarm | Cover, Pivot Pin, Swingarm | 1 | $4.46 | Available to order | 1 |
| 16 | T3450295 Fir Tree, Dia 5.7 x 12.7 | Fir Tree, Dia 5.7 x 12.7 | 1 | $1.50 | Available to order | 1 |
