Sliding Carriage Kit
Schematic
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9508171 Adventure Sliding Carriage Kit | Adventure Sliding Carriage Kit | 1 | $199.80 | Obsolete | View Details |
| 2 | T2351532 Sliding Carriage Assembly | Sliding Carriage Assembly | 1 | $150.17 | Available to order | 1 |
| 3 | T2353276 Subharness, Top Box, F, 2-pin | Subharness, Top Box, F, 2-pin | 1 | $57.03 | Available to order | 1 |
| 4 | T2350534 Harness Cover, Sliding Carriage | Harness Cover, Sliding Carriage | 1 | $8.90 | Available to order | 1 |
| 5 | T3331680 Screw, Pan/HD, S/Tap, 4.2 x 13 | Screw, Pan/HD, S/Tap, 4.2 x 13 | 3 | $2.37 | Available to order | 3 |
| 6 | T3200601 Bolt, HHF, M8 x 40, Slv | Bolt, HHF, M8 x 40, Slv | 4 | $3.04 | Available to order | 4 |
| 7 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 4 | $2.45 | Available to order | 4 |
| 8 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 1 | $0.89 | Available to order | 1 |
| 9 | T2351245 Moulding, Terminal Support SC | Moulding, Terminal Support SC | 1 | $7.62 | Available to order | 1 |
| 10 | T2350548 Spares Kit, Sliding Carriage | Spares Kit, Sliding Carriage | 1 | $22.50 | Unavailable | View Details |
