Fog Lights
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2701465 Fog Lamp, LED | Fog Lamp, LED | 2 | $245.24 | Available to order | 2 |
| 2 | T9830063 Bracket, Fog Lamp, RHS | Bracket, Fog Lamp, RHS | 1 | $57.03 | Available to order | 1 |
| 3 | T9830064 Bracket, Fog Lamp, LHS | Bracket, Fog Lamp, LHS | 1 | $57.03 | Available to order | 1 |
| 4 | T2701580 Shroud, Fog Lamp, LH | Shroud, Fog Lamp, LH | 1 | $56.73 | Available to order | 1 |
| 5 | T2701585 Shroud, Fog Lamp, RH | Shroud, Fog Lamp, RH | 1 | $56.73 | Available to order | 1 |
| 6 | T3330649 Screw, Pan/Hd, Tx, M5 x 12, Slv | Screw, Pan/Hd, Tx, M5 x 12, Slv | 4 | $5.67 | Available to order | 4 |
| 7 | T3550249 Washer, 11 x 5.1 x 0.8 | Washer, 11 x 5.1 x 0.8 | 4 | $2.25 | Available to order | 4 |
| 8 | T3330943 Screw, But/Hd, M5 x 14, Slv | Screw, But/Hd, M5 x 14, Slv | 4 | $4.92 | Available to order | 4 |
| 9 | T3700062 Fir Tree Clip | Fir Tree Clip | 2 | $2.95 | Available to order | 2 |
| 10 | T3202304 Bolt, RHHF, M6 x 20, Slv | Bolt, RHHF, M6 x 20, Slv | 4 | $5.30 | Available to order | 4 |
