Rear Mudguard
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2310531 Battery Tray, Moulding | Battery Tray, Moulding | 1 | $60.56 | Out of Stock | Notify Me |
| 2 | T3331061 Bolt, But/Hd, M5 x 11, Shld, Slv | Bolt, But/Hd, M5 x 11, Shld, Slv | 2 | $5.02 | Available to order | 2 |
| 3 | T3330275 Screw, But/Hd, Tx, M8 x 20, Enc | Screw, But/Hd, Tx, M8 x 20, Enc | 2 | $3.59 | Available to order | 2 |
| 4 | T3555033 Washer, 8.4 x 24 x 2 | Washer, 8.4 x 24 x 2 | 2 | $2.74 | Available to order | 2 |
| 5 | T2313214 Insert, Battery | Insert, Battery | 1 | $7.42 | Available to order | 1 |
| 6 | T2313169 Cover, RSU Hose, Moulding | Cover, RSU Hose, Moulding | 1 | $8.88 | Backorder — Late August 2026 | 1 |
| 7 | T3701150 Plastic Rivet, Push Release | Plastic Rivet, Push Release | 2 | $0.97 | Available to order | 2 |
| 8 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 3 | $1.72 | Available to order | 3 |
| 9 | T2310567 Spacer, Rubber, Number Plate Hanger | Spacer, Rubber, Number Plate Hanger | 1 | $10.72 | Available to order | 1 |
| 10 | T2310517 Number Plate, Upper, Mldg | Number Plate, Upper, Mldg | 1 | $64.51 | Available to order | 1 |
| 11 | T2310568 Fixing Plate, Number Plate | Fixing Plate, Number Plate | 1 | $7.62 | Available to order | 1 |
| 12 | T2310518 Number Plate, Lower, Moulding | Number Plate, Lower, Moulding | 1 | $31.31 | Available to order | 1 |
| 13 | T3205067 Bolt, HHF, Lghtd, M6 x 25, Slv | Bolt, HHF, Lghtd, M6 x 25, Slv | 3 | $2.46 | Available to order | 3 |
| 14 | T3010127 Flanged Sleeve, M6 | Flanged Sleeve, M6 | 2 | $5.55 | Available to order | 2 |
| 15 | T3010144 Flanged Sleeve, M6 x 9.5 x 10.5 | Flanged Sleeve, M6 x 9.5 x 10.5 | 1 | $3.77 | Available to order | 1 |
| 16 | T3330696 Screw, But/Hd, M5 X 16, Slv | Screw, But/Hd, M5 X 16, Slv | 4 | $5.69 | Available to order | 4 |
| 17 | T2320000 Number Plate, Moulding | Number Plate, Moulding | 1 | $53.29 | Available to order | 1 |
| 18 | T2310566 Spray Deflector, Moulding | Spray Deflector, Moulding | 1 | $17.27 | Out of Stock | Notify Me |
| 19 | T3332655 Screw, But/HD, M5 x 12. Slv | Screw, But/HD, M5 x 12. Slv | 2 | $0.89 | Unavailable | View Details |
| 20 | T3350010 Locknut, Flgd, M5 | Locknut, Flgd, M5 | 2 | $2.25 | Available to order | 2 |
| 21 | T2312500 Battery Tray Cover, Mldg | Battery Tray Cover, Mldg | 1 | $7.11 | Out of Stock | Notify Me |
| 22 | T3350161 Nut, Captive, M5 | Nut, Captive, M5 | 2 | $4.55 | Available to order | 2 |
| 23 | T3700282 S Panel Clip, 2mm | S Panel Clip, 2mm | 4 | $1.44 | Available to order | 4 |
| 24 | T3700290 Clip, Panel, Bayonet | Clip, Panel, Bayonet | 2 | $2.37 | Available to order | 2 |
