Front Wheel
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 52TA1360 Front Wheel Assembly | Front Wheel Assembly | 1 | $522.53 | Out of Stock | Notify Me |
| 2 | TA131012 Spindle | Spindle | 1 | $63.46 | Available to order | 1 |
| 3 | TA131017 Collar | Collar | 2 | $4.74 | Available to order | 2 |
| 4 | KPBC6203 Bearing Ball | Bearing Ball | 2 | $17.90 | Available to order | 2 |
| 5 | TA131008 Spacer | Spacer | 1 | $34.58 | Available to order | 1 |
| 6 | KEBB4017 Circlip Internal | Circlip Internal | 1 | $1.24 | Available to order | 1 |
| 7 | DK151026 Valve, Tubeless Tyre | Valve, Tubeless Tyre | 1 | $2.25 | Available to order | 1 |
| 8 | 39162619 Oil Seal, 25 x 4 x 5 | Oil Seal, 25 x 4 x 5 | 2 | $1.58 | Available to order | 2 |
| 10 | TA233325 Wheel Decal LH, Yellow | Wheel Decal LH, Yellow | 1 | $12.04 | Out of Stock | Notify Me |
| 10 | TA233335 Wheel Decal LH, Black | Wheel Decal LH, Black | 1 | $12.04 | Out of Stock | Notify Me |
| 10 | TA233346 Wheel Decal LH, Red | Wheel Decal LH, Red | 1 | $12.04 | Backorder — Late August 2026 | 1 |
| 11 | TA233326 Wheel Decal RH, Yellow | Wheel Decal RH, Yellow Not Illustrated | 1 | $12.04 | Backorder — Early August 2026 | 1 |
| 11 | TA233336 Wheel Decal RH, Black | Wheel Decal RH, Black Not Illustrated | 1 | $12.04 | Out of Stock | Notify Me |
| 11 | TA233347 Wheel Decal RH, Red | Wheel Decal RH, Red Not Illustrated | 1 | $12.04 | Backorder — Mid August 2026 | 1 |
