Engine Management
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1293199 ECU, Base, KTKS | ECU, Base, KTKS AR, BL, CH, DE, EF, ES, FR, GR, IT, JP, NL, SE, UK, XA & ZA only. | 1 | $2137.71 | Available to order | 1 |
| 2 | T1290975 Air Pressure Sensor | Air Pressure Sensor | 1 | $144.49 | Available to order | 1 |
| 3 | T3050301 Screw, Cap/Hd. M5 x 20, Blk | Screw, Cap/Hd. M5 x 20, Blk | 1 | $2.19 | Backorder — Late August 2026 | 1 |
| 4 | T1296777 Hose, Map Sensor | Hose, Map Sensor | 3 | $10.17 | Backorder — Early August 2026 | 3 |
| 5 | T1296555 Hose, Map, Spigot | Hose, Map, Spigot | 2 | $6.65 | Out of Stock | Notify Me |
| 6 | T1291504 Coil, Ignition | Coil, Ignition | 3 | $195.81 | Available to order | 3 |
| 7 | T1290023 Spark plug | Spark plug All Except BR. | 3 | $17.50 | Available to order | 3 |
| 8 | T2100808 Sensor, Engine Coolant | Sensor, Engine Coolant All Except BR. | 1 | $54.02 | Available to order | 1 |
| 8 | T2100812 Engine Coolant Sensor | Engine Coolant Sensor BR only. | 1 | $63.70 | Out of Stock | Notify Me |
| 9 | T3550571 Washer, Cu, OD 16 x ID 12.5 | Washer, Cu, OD 16 x ID 12.5 | 1 | $5.07 | Available to order | 1 |
| 10 | T1290088 Sensor, Air Temperature | Sensor, Air Temperature | 1 | $64.75 | Available to order | 1 |
| 11 | T1242929 Connector, 4 Way | Connector, 4 Way | 1 | $10.90 | Available to order | 1 |
| 12 | T1299232 Sensor, Gear Position | Sensor, Gear Position | 1 | $119.76 | Available to order | 1 |
| 13 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv | 2 | $4.55 | Available to order | 2 |
| 14 | T3600267 O Ring, ID 26.65 x Dia 2.62 | O Ring, ID 26.65 x Dia 2.62 | 2 | $1.51 | Available to order | 2 |
| 15 | T3700286 Hose Guide | Hose Guide | 1 | $6.65 | Available to order | 1 |
| 17 | T1296888 Hose, Map Drain | Hose, Map Drain | 2 | $8.01 | Out of Stock | Notify Me |
| 18 | T1296996 Restrictor | Restrictor | 2 | $2.50 | Unavailable | View Details |
| 19 | T1292075 Hose, Throttle Body, Cyl 1 | Hose, Throttle Body, Cyl 1 | 1 | $3.24 | Available to order | 1 |
| 20 | T1292076 Hose, Throttle Body, Cyl 2 | Hose, Throttle Body, Cyl 2 | 1 | $3.24 | Out of Stock | Notify Me |
| 21 | T1292077 Hose, Throttle Body, Cyl 3 | Hose, Throttle Body, Cyl 3 | 1 | $3.24 | Available to order | 1 |
| 22 | T3701240 Band, Rubber | Band, Rubber | 1 | $2.85 | Out of Stock | Notify Me |
| 23 | T1246969 Cap, Evap | Cap, Evap | 2 | $2.67 | Backorder — Mid August 2026 | 2 |
| 24 | T2040811 Twin Clip, Brake Hose | Twin Clip, Brake Hose | 2 | $2.63 | Available to order | 2 |
