Front Indicators
Parts (15)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2702012 Indicator Assy, RH | Indicator Assy, RH | 1 | $65.49 | Available to order | 1 |
| 2 | T2702011 Indicator Assy, LH | Indicator Assy, LH | 1 | $65.49 | Available to order | 1 |
| 3 | T2700425 Lamp body | Lamp body | 2 | $38.60 | Available to order | 2 |
| 4 | T2700445 Lens | Lens | 2 | $12.76 | Available to order | 2 |
| 5 | T2700426 Stem | Stem | 2 | $16.56 | Available to order | 2 |
| 7 | 2700032-T0301 Bulb | Bulb | 2 | $4.52 | Obsolete | View Details |
| 8 | T2700428 Screw | Screw | 2 | $1.21 | Available to order | 2 |
| 9 | T2700441 Screw | Screw | 2 | $1.21 | Available to order | 2 |
| 10 | T3350302 Nut, M10, Slv | Nut, M10, Slv | 2 | $0.89 | Available to order | 2 |
| 11 | T3550229 Washer, 15.2 x 10 x 1, Plated | Washer, 15.2 x 10 x 1, Plated | 2 | $1.07 | Available to order | 2 |
| 12 | T3551140 Washer, Serrated, Lock, M10 | Washer, Serrated, Lock, M10 | 2 | $0.97 | Available to order | 2 |
| 13 | T2701083 Indicator Bracket, Front | Indicator Bracket, Front | 1 | $13.26 | Available to order | 1 |
| 14 | T2350030 Boot, Indicator, Nut/Stud | Boot, Indicator, Nut/Stud | 2 | $3.77 | Available to order | 2 |
| 15 | T3700108 Clip, Cable, 14.3 x 10 | Clip, Cable, 14.3 x 10 | 2 | $3.24 | Available to order | 2 |
| 16 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 2 | $3.50 | Available to order | 2 |
