Gearchange Mechanism
Parts (18)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2083411 Gear Pedal Spares Kit | Gear Pedal Spares Kit > AF9793 All Except BR & IN; > AG0880 BR & IN Only | 1 | $113.10 | Available to order | 1 |
| 1 | T2082696 Gearchange Pedal | Gearchange Pedal AF9794 > All Except BR & IN; AG0881 > BR & IN Only | 1 | $31.37 | Available to order | 1 |
| 2 | T3750020 Bush, PAP, 1215 P14 | Bush, PAP, 1215 P14 | 1 | $7.30 | Available to order | 1 |
| 3 | T2083204 Gearchange Rubber | Gearchange Rubber | 1 | $1.84 | Available to order | 1 |
| 4 | T3331520 Bolt, Shld, M8 x 1.25, Slv, Enc | Bolt, Shld, M8 x 1.25, Slv, Enc | 1 | $10.63 | Available to order | 1 |
| 5 | T3350715 Nut, Flanged, Domed, M8 | Nut, Flanged, Domed, M8 | 2 | $1.13 | Available to order | 2 |
| 6 | T2083720 Ball, Ball Joint, M8 | Ball, Ball Joint, M8 | 2 | $26.46 | Available to order | 2 |
| 7 | T2086072 Seal, Ball Joint | Seal, Ball Joint | 2 | $7.66 | Available to order | 2 |
| 8 | T2088604 Clamp, Gearchange | Clamp, Gearchange AF9794 > All Except BR & IN; AG0881 > - BR & IN Only | 1 | $38.12 | Available to order | 1 |
| 9 | T3205094 Bolt, HHF, Lghtd, M6 x 20, Enc | Bolt, HHF, Lghtd, M6 x 20, Enc | 1 | $5.69 | Backorder — Mid August 2026 | 1 |
| 10 | T2083219 Gearchange Rod | Gearchange Rod | 1 | $18.50 | Available to order | 1 |
| 11 | T3350306 Nut, M6, Black | Nut, M6, Black | 1 | $1.51 | Available to order | 1 |
| 12 | T3350308 Nut, M6, Black, LH | Nut, M6, Black, LH | 1 | $1.51 | Out of Stock | Notify Me |
| 13 | T2086999 Ball Joint, Right Hand Thread | Ball Joint, Right Hand Thread | 1 | $22.44 | Available to order | 1 |
| 14 | T2086888 Ball Joint, Left Hand Thread | Ball Joint, Left Hand Thread | 1 | $23.08 | Available to order | 1 |
| 15 | T2086073 Clip, Ball Joint | Clip, Ball Joint | 2 | $2.37 | Available to order | 2 |
| 16 | T3335012 Screw, But/Hd, Skt, M8 x 25 | Screw, But/Hd, Skt, M8 x 25 | 2 | $8.33 | Available to order | 2 |
| 17 | T2086612 Gearchange Bracket | Gearchange Bracket | 1 | $30.03 | Available to order | 1 |
