Front Forks and Yokes 44302 »
Parts (32)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2042821 Stanchion lh | Stanchion lh | 1 | $934.57 | Obsolete | View Details |
| 2 | T2042822 Stanchion rh | Stanchion rh | 1 | $934.57 | Obsolete | View Details |
| 3 | T2042917 Tube outer | Tube outer LH | 1 | $499.35 | Obsolete | View Details |
| 3 | T2042916 Tube outer | Tube outer RH | 1 | $499.35 | Obsolete | View Details |
| 4 | T2045862 Guide, Bush | Guide, Bush | 2 | $13.01 | Available to order | 2 |
| 5 | T2046246 Seal, Spacer | Seal, Spacer | 2 | $6.37 | Backorder — Late September 2026 | 2 |
| 6 | T2042894 Oil seal | Oil seal | 2 | $22.15 | Available to order | 2 |
| 7 | T2046248 Stop Ring | Stop Ring | 2 | $7.28 | Available to order | 2 |
| 8 | T2042897 Dust seal | Dust seal | 2 | $20.76 | Obsolete | View Details |
| 9 | T2042906 Oil lock | Oil lock | 2 | $10.95 | Available to order | 2 |
| 10 | T2042888 Fork Leg Piston Ring | Fork Leg Piston Ring | 2 | $10.84 | Available to order | 2 |
| 11 | T2042918 Cylinder assembly | Cylinder assembly | 2 | $274.54 | Obsolete | View Details |
| 12 | T2042915 Tube inner | Tube inner | 2 | $489.55 | Available to order | 2 |
| 13 | T2042900 Spring | Spring | 2 | — | Obsolete | View Details |
| 14 | T2042902 Guide spring | Guide spring | 2 | $13.17 | Available to order | 2 |
| 15 | T2042903 Spacer | Spacer | 2 | $10.32 | Out of Stock | Notify Me |
| 16 | T2042904 Cap | Cap | 2 | $80.23 | Available to order | 2 |
| 17 | T2042908 Capscrew | Capscrew | 2 | $11.31 | Available to order | 2 |
| 18 | T2042907 Sealing washer | Sealing washer | 2 | $1.21 | Available to order | 2 |
| 19 | T2040917 Yoke | Yoke » 45633 Upper | 1 | $405.06 | Obsolete | View Details |
| 19 | T2043150 Yoke | Yoke 45634 » Upper | 1 | $244.64 | Obsolete | View Details |
| 20 | T2042830 Yoke assembly | Yoke assembly Lower | 1 | $459.90 | Obsolete | View Details |
| 21 | T3050073 Capscrew | Capscrew M8 x 40mm | 10 | $6.27 | Available to order | 10 |
| 22 | T3450250 Moss Plug | Moss Plug | 3 | $1.50 | Available to order | 3 |
| 23 | T2040188 Washer | Washer | 1 | $6.81 | Obsolete | View Details |
| 24 | T2040060 Nut | Nut | 1 | $25.75 | Available to order | 1 |
| 25 | T2042905 O Ring, Fork Seal | O Ring, Fork Seal | 2 | $3.61 | Available to order | 2 |
| 26 | T2040259 Cover, Headstock Assy | Cover, Headstock Assy Lower | 1 | $25.23 | Available to order | 1 |
| 27 | T2140210 Adjuster Nut, Upper | Adjuster Nut, Upper | 1 | $3.61 | Available to order | 1 |
| 28 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 10 | $4.46 | Available to order | 10 |
| 29 | T3900405 Badge | Badge | 1 | $23.07 | Available to order | 1 |
| 30 | T3300090 Rivet | Rivet | 4 | $1.18 | Available to order | 4 |
