Footrests & Mountings
Parts (51)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2080073-T0301 Footrest assembly front | Footrest assembly front » 2899 LH | 1 | $112.13 | Out of Stock | Notify Me |
| 1 | 2080105-T0301 Footrest assembly front | Footrest assembly front 2900 » » 4901 LH | 1 | $93.36 | Obsolete | View Details |
| 1 | 2080102-T0301 Footrest assembly front | Footrest assembly front 4902 » LH | 1 | $87.17 | Obsolete | View Details |
| 2 | 2080106-T0301 Footrest assembly front | Footrest assembly front » 2899 RH | 1 | $105.19 | Obsolete | View Details |
| 2 | 2080103-T0301 Footrest assembly front | Footrest assembly front 4902 » RH | 1 | $88.91 | Obsolete | View Details |
| 3 | 2080056-T0301 Footrest assembly rear | Footrest assembly rear LH | 1 | $117.87 | Backorder — Late August 2026 | 1 |
| 4 | 2080057-T0301 Footrest assembly rear | Footrest assembly rear RH * PART NO LONGER AVAILABLE * | 1 | $107.35 | Obsolete | View Details |
| 5 | 2080031-T0301 Rubber | Rubber *Part No Longer Available* | 4 | $31.72 | Obsolete | View Details |
| 6 | T3330696 Screw, But/Hd, M5 X 16, Slv | Screw, But/Hd, M5 X 16, Slv | 8 | $5.69 | Available to order | 8 |
| 7 | 2080071-T0301 Bracket pivot | Bracket pivot » 4901 LH front | 1 | $16.13 | Obsolete | View Details |
| 7 | 2080023-T0301 Pivot bracket | Pivot bracket 4902 » LH front | 1 | $13.21 | Obsolete | View Details |
| 8 | 2080024-T0301 Pivot bracket | Pivot bracket Rear | 2 | $17.88 | Obsolete | View Details |
| 9 | T2080722 Pivot Pin, Footrest | Pivot Pin, Footrest | 2 | $6.45 | Available to order | 2 |
| 10 | T3500210 Circlip, Ext, 8 x 1 | Circlip, Ext, 8 x 1 | 2 | $2.14 | Available to order | 2 |
| 11 | T2080819 Return Spring, Footrest | Return Spring, Footrest | 2 | $6.29 | Available to order | 2 |
| 12 | 2080033-T0301 Peg | Peg » 4901 | 2 | $11.83 | Obsolete | View Details |
| 12 | 2080104-T0301 Peg | Peg 4902 » | 2 | $13.66 | Obsolete | View Details |
| 13 | 2080027-T0301 Footrest | Footrest LH front | 1 | $39.18 | Available to order | 1 |
| 14 | 2080028-T0301 Footrest | Footrest RH front | 1 | $39.18 | Available to order | 1 |
| 15 | 2080029-T0301 Footrest | Footrest LH rear | 1 | $58.92 | Available to order | 1 |
| 16 | 2080030-T0301 Footrest | Footrest RH rear | 1 | $58.92 | Available to order | 1 |
| 17 | T2080721 Pivot Pin, Footrest | Pivot Pin, Footrest | 2 | $6.45 | Available to order | 2 |
| 18 | T2080724 Spring, Footrest (Rear) | Spring, Footrest (Rear) | 2 | $2.10 | Available to order | 2 |
| 19 | T2080725 Detent Ball | Detent Ball | 2 | $1.72 | Available to order | 2 |
| 20 | T3350250 Locknut, Flanged, M10 | Locknut, Flanged, M10 | 2 | $4.16 | Available to order | 2 |
| 21 | 2080069-T0301 Control plate lh | Control plate lh » 2515 | 1 | $95.68 | Obsolete | View Details |
| 21 | 2080077-T0301 Control plate lh | Control plate lh 2516 » » 3827 | 1 | $95.68 | Obsolete | View Details |
| 21 | 2080112-T0301 Control plate lh | Control plate lh 4902 » » 16921 | 1 | $95.68 | Obsolete | View Details |
| 21 | T2080312 Control plate lh | Control plate lh 16922 » | 1 | $95.68 | Obsolete | View Details |
| 22 | 2080068-T0301 Control plate rh | Control plate rh » 2515 | 1 | $95.68 | Obsolete | View Details |
| 22 | 2080076-T0301 Control plate rh | Control plate rh 2516 » » 3827 | 1 | $48.12 | Obsolete | View Details |
| 22 | 2080111-T0301 Control plate rh | Control plate rh 4902 » » 16921 | 1 | $95.68 | Obsolete | View Details |
| 22 | T2080311 Control plate rh | Control plate rh 16922 » | 1 | $95.68 | Obsolete | View Details |
| 23 | 2080079-T0301 Footrest hanger | Footrest hanger » 2515 LH | 1 | $45.97 | Obsolete | View Details |
| 23 | 2080087-T0301 Footrest hanger | Footrest hanger 2516 » » 3827 LH | 1 | $12.46 | Out of Stock | Notify Me |
| 23 | 2080200-T0301 Footrest hanger | Footrest hanger 3828 » » 4502 LH | 1 | $46.88 | Obsolete | View Details |
| 23 | 2080121-T0301 Footrest hanger | Footrest hanger 4503 » » 4901 LH | 1 | $12.46 | Out of Stock | Notify Me |
| 23 | 2080119-T0301 Footrest hanger | Footrest hanger 4902 » LH | 1 | $80.54 | Obsolete | View Details |
| 24 | 2080078-T0301 Footrest hanger | Footrest hanger » 2515 RH | 1 | $52.41 | Obsolete | View Details |
| 24 | 2080086-T0301 Footrest hanger | Footrest hanger 2516 » » 3827 RH | 1 | $52.41 | Obsolete | View Details |
| 24 | 2080190-T0301 Footrest hanger | Footrest hanger 3828 » » 4502 RH | 1 | $52.41 | Obsolete | View Details |
| 24 | 2080122-T0301 Footrest hanger | Footrest hanger 4503 » » 4901 RH | 1 | $83.63 | Obsolete | View Details |
| 24 | 2080120-T0301 Footrest hanger | Footrest hanger 4902 » RH | 1 | $72.03 | Obsolete | View Details |
| 25 | T3200090 Bolt, RHHF, M8 x 30, Slv, Enc | Bolt, RHHF, M8 x 30, Slv, Enc | 6 | $2.10 | Available to order | 6 |
| 26 | T3200042 Bolt, M8 x 55 | Bolt, M8 x 55 M8 x 55mm | 4 | $4.02 | Obsolete | View Details |
| 27 | 2070726-T0301 Clamp | Clamp » 4901 | 2 | $10.46 | Obsolete | View Details |
| 27 | 2070727-T0301 Clamp | Clamp 4902 » LH | 1 | $10.46 | Obsolete | View Details |
| 28 | 3330600-T0301 Screw | Screw M10 x 30mm | 2 | $5.03 | Obsolete | View Details |
| 29 | 2080072-T0301 Bracket pivot | Bracket pivot » 4901 RH front | 1 | $16.26 | Obsolete | View Details |
| 30 | T3450049 Plug | Plug 4902 » 20mm | 2 | $3.29 | Obsolete | View Details |
| 31 | 3450046-T0301 Plug | Plug 4902 » 11mm - PART NO LONGER AVAILABLE | 2 | $1.23 | Obsolete | View Details |
