Headlight/Mountings > VIN 9082
Parts (33)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2700080-T0301 Screw csk head | Screw csk head M4 x 45mm | 1 | $2.98 | Obsolete | View Details |
| 2 | T2700081 Screw, C'sunk, Phil, M5 x .08 x 16 | Screw, C'sunk, Phil, M5 x .08 x 16 M5 x 14mm | 2 | $1.27 | Available to order | 2 |
| 3 | 2700082-T0301 Shouldered bolt | Shouldered bolt M5 x 12mm | 2 | $3.77 | Available to order | 2 |
| 4 | T2700493 Nut & Washer Assy, M5, Slv | Nut & Washer Assy, M5, Slv | 2 | $1.79 | Available to order | 2 |
| 5 | T2700084 Nut, Square, M4 | Nut, Square, M4 M4 | 1 | $3.77 | Available to order | 1 |
| 6 | 2700085-T0301 Washer | Washer | 2 | $3.77 | Backorder — Late August 2026 | 2 |
| 7 | T2700004 Rim, Headlight | Rim, Headlight | 1 | $84.58 | Available to order | 1 |
| 8 | T2701186 Screw, Pan/HD, M3 x 12 | Screw, Pan/HD, M3 x 12 | 2 | $1.13 | Available to order | 2 |
| 9 | T2700418 Rim, Headlight Retainer | Rim, Headlight Retainer | 1 | $84.58 | Available to order | 1 |
| 10 | T2700722 Spring | Spring | 1 | $4.19 | Available to order | 1 |
| 11 | T3551088 Washer, 4.25 x 8 x 0.8 | Washer, 4.25 x 8 x 0.8 M4 | 1 | $0.97 | Available to order | 1 |
| 12 | 2700012-T0301 Mounting ring | Mounting ring | 1 | $81.75 | Available to order | 1 |
| 13 | T2700236 Bowl | Bowl | 1 | $71.84 | Obsolete | View Details |
| 14 | T3020351 Grommet, 56 x 0.75 x 52 | Grommet, 56 x 0.75 x 52 | 1 | $3.17 | Available to order | 1 |
| 15 | 2700062-T0301 Bracket | Bracket » 2490 | 2 | $55.73 | Obsolete | View Details |
| 15 | 2700063-T0301 Bracket | Bracket 2491 » » 4901 | 2 | $49.80 | Obsolete | View Details |
| 15 | 2700162-T0301 Bracket | Bracket 4902 » » 9082 Black | 2 | $55.73 | Obsolete | View Details |
| 16 | T3020010 Grommet, Mounting Tube | Grommet, Mounting Tube | 4 | $3.77 | Out of Stock | Notify Me |
| 17 | 2700029-T0301 Subframe | Subframe » 4901 | 1 | $31.07 | Obsolete | View Details |
| 17 | 2700129-T0301 Subframe | Subframe 4902 » » 9082 | 1 | $71.77 | Obsolete | View Details |
| 18 | T3050059 Screw, Skt/Hd, M6 X 20, S/S | Screw, Skt/Hd, M6 X 20, S/S » 4901 M6 x 20mm | 4 | $1.13 | Available to order | 4 |
| 18 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv 4902 » » 9082 M6 x 20mm | 4 | $4.55 | Available to order | 4 |
| 19 | T3205254 Bolt, HHF, Lghtd, M8 x 20, Slv | Bolt, HHF, Lghtd, M8 x 20, Slv » 4901 | 2 | $1.62 | Available to order | 2 |
| 19 | 3200032-T0301 Bolt | Bolt 4902 » » 9082 M8 x 20mm | 2 | $2.25 | Obsolete | View Details |
| 20 | T3331044 Screw, Pan/Hd, Tx, M6 x 16, Slv | Screw, Pan/Hd, Tx, M6 x 16, Slv M6 x 16mm | 2 | $0.97 | Available to order | 2 |
| 21 | 3550014-T0301 Washer | Washer **Part No Longer Available** | 2 | $0.96 | Obsolete | View Details |
| 22 | T3010702 Flanged Sleeve, 6.4 x 10 x 8.5 | Flanged Sleeve, 6.4 x 10 x 8.5 | 4 | $5.78 | Available to order | 4 |
| 23 | T2700355 Headlight & Rim Assy, LH | Headlight & Rim Assy, LH LH dip UK, NZ, AU, JP, ZA, CY, HK, MY | 1 | $285.16 | Available to order | 1 |
| 23 | T2701011 Headlight Assy, RH | Headlight Assy, RH RH dip | 1 | $268.77 | Available to order | 1 |
| 24 | T2700001 Bulb, H4 60/55W, 12V, Type 1, Clear | Bulb, H4 60/55W, 12V, Type 1, Clear | 1 | $17.69 | Available to order | 1 |
| 24 | 2700101-T0301 Bulb halogen | Bulb halogen FR - Yellow bulb (use White bulb after January 1993) | 1 | $83.49 | Obsolete | View Details |
| 25 | T2700210 Bulb, Parking Lamp, 12V 4W | Bulb, Parking Lamp, 12V 4W 4W | 1 | $4.12 | Available to order | 1 |
| 26 | T2701017 Subharness, Headlight | Subharness, Headlight Outer cover not supplied | 1 | $26.56 | Available to order | 1 |
