Bodywork Fixings
Parts (15)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 3550055-T0301 Washer, Plastic | Washer, Plastic | 11 | $0.89 | Available to order | 11 |
| 2 | T3331062 Bolt, But/Hd, M5 x 16, Shld, Slv | Bolt, But/Hd, M5 x 16, Shld, Slv M5 x 16mm | 5 | $6.94 | Available to order | 5 |
| 3 | T3350123 Nut, Captive, M5, Non-Secured | Nut, Captive, M5, Non-Secured | 4 | $2.48 | Available to order | 4 |
| 4 | T3330090 Bolt | Bolt M6 x 24mm | 2 | $5.56 | Unavailable | View Details |
| 5 | 3550060-T0301 Washer, Plastic, 14.3 x 2.0 | Washer, Plastic, 14.3 x 2.0 | 4 | $0.70 | Obsolete | View Details |
| 6 | T3020029 Grommet, Side Panel | Grommet, Side Panel | 8 | $2.55 | Available to order | 8 |
| 7 | T3202319 Bolt, HHF, M8 x 35, Slv | Bolt, HHF, M8 x 35, Slv | 2 | $2.63 | Available to order | 2 |
| 8 | 3010220-T0301 Flanged sleeve | Flanged sleeve ** Part No Longer Available ** | 2 | $6.05 | Obsolete | View Details |
| 9 | T3021250 Grommet, Dia 18x4 | Grommet, Dia 18x4 | 2 | $2.95 | Available to order | 2 |
| 10 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv M6 x 12mm | 2 | $1.72 | Available to order | 2 |
| 11 | T3010062 Flanged Sleeve, M6 x 7.8 x 2.85 | Flanged Sleeve, M6 x 7.8 x 2.85 | 2 | $7.14 | Available to order | 2 |
| 12 | T3200135 Bolt | Bolt M8 x 45mm | 2 | $1.09 | Obsolete | View Details |
| 13 | T3550275 Washer-m8 | Washer-m8 | 2 | $0.67 | Available to order | 2 |
| 14 | T3010270 Sleeve | Sleeve ** PART NO LONGER AVAILABLE ** | 2 | $15.37 | Obsolete | View Details |
| 15 | T3555033 Washer, 8.4 x 24 x 2 | Washer, 8.4 x 24 x 2 | 2 | $2.74 | Available to order | 2 |
