Front Forks and Yokes 96152 » » 98479
Parts (37)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2042801 Stanchion assembly | Stanchion assembly LH | 1 | $1033.51 | Out of Stock | Notify Me |
| 2 | T2042802 Stanchion assembly | Stanchion assembly RH | 1 | $934.57 | Obsolete | View Details |
| 3 | T2042927 Tube outer | Tube outer LH | 1 | $514.30 | Obsolete | View Details |
| 3 | T2042926 Tube outer | Tube outer RH | 1 | $514.30 | Obsolete | View Details |
| 4 | T2045862 Guide, Bush | Guide, Bush | 2 | $13.01 | Available to order | 2 |
| 5 | T2046246 Seal, Spacer | Seal, Spacer | 2 | $6.37 | Backorder — Late September 2026 | 2 |
| 6 | T2042894 Oil seal | Oil seal | 2 | $22.15 | Available to order | 2 |
| 7 | T2046248 Stop Ring | Stop Ring | 2 | $7.28 | Available to order | 2 |
| 8 | T2042897 Dust seal | Dust seal | 2 | $20.76 | Obsolete | View Details |
| 9 | T2042906 Oil lock | Oil lock | 2 | $10.95 | Available to order | 2 |
| 10 | T2042888 Fork Leg Piston Ring | Fork Leg Piston Ring | 2 | $10.84 | Available to order | 2 |
| 11 | T2042928 Cylinder assembly | Cylinder assembly | 2 | $282.76 | Obsolete | View Details |
| 12 | T3450062 Plug, Plastic, Black | Plug, Plastic, Black | 2 | $1.50 | Available to order | 2 |
| 13 | T2042915 Tube inner | Tube inner | 2 | $489.55 | Available to order | 2 |
| 14 | T2042901 Spring | Spring | 2 | $104.33 | Available to order | 2 |
| 15 | T2042902 Guide spring | Guide spring | 2 | $13.17 | Available to order | 2 |
| 16 | T2042903 Spacer | Spacer | 2 | $10.32 | Out of Stock | Notify Me |
| 17 | T2042904 Cap | Cap | 2 | $80.23 | Available to order | 2 |
| 18 | T2042908 Capscrew | Capscrew | 2 | $11.31 | Available to order | 2 |
| 19 | T2042907 Sealing washer | Sealing washer | 2 | $1.21 | Available to order | 2 |
| 20 | T2042815 Yoke assembly | Yoke assembly Upper | 1 | $211.59 | Obsolete | View Details |
| 21 | T2042810 Yoke assembly | Yoke assembly Lower | 1 | $374.64 | Obsolete | View Details |
| 22 | T3050073 Capscrew | Capscrew M8 x 40mm | 10 | $6.27 | Available to order | 10 |
| 23 | T3450250 Moss Plug | Moss Plug | 1 | $1.50 | Available to order | 1 |
| 24 | T2040188 Washer | Washer | 1 | $6.81 | Obsolete | View Details |
| 25 | T2040060 Nut | Nut | 1 | $25.75 | Available to order | 1 |
| 26 | T2042905 O Ring, Fork Seal | O Ring, Fork Seal | 2 | $3.61 | Available to order | 2 |
| 27 | T2040259 Cover, Headstock Assy | Cover, Headstock Assy Lower | 1 | $25.23 | Available to order | 1 |
| 28 | T2140210 Adjuster Nut, Upper | Adjuster Nut, Upper | 1 | $3.61 | Available to order | 1 |
| 29 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 4 | $4.46 | Available to order | 4 |
| 30 | T2040156 Cover | Cover | 1 | $25.31 | Obsolete | View Details |
| 31 | T3450270 Retainer | Retainer | 2 | $0.81 | Available to order | 2 |
| 32 | T3450265 Firtree plug | Firtree plug PART NO LONGER AVAILABLE | 2 | $1.36 | Obsolete | View Details |
| 33 | T3900450 Badge, Oval, Plastic | Badge, Oval, Plastic | 1 | $9.09 | Backorder — Late October 2026 | 1 |
| 34 | T2500028 Bracket | Bracket | 1 | $3.82 | Available to order | 1 |
| 35 | T2040878 Clip cable | Clip cable | 1 | $2000.78 | Obsolete | View Details |
| 36 | T3331043 Screw, Pan/Hd, Tx, M6 x 12, Slv | Screw, Pan/Hd, Tx, M6 x 12, Slv M6 x 12mm Black | 1 | $1.04 | Available to order | 1 |
