Front Brake Caliper and Disc
Parts (13)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2020201 Caliper assembly | Caliper assembly LH | 1 | $604.56 | Obsolete | View Details |
| 1 | T2020301 Caliper assembly | Caliper assembly RH | 1 | $675.95 | Obsolete | View Details |
| 2 | T3205796 Bolt, HHF, Lghtd, M10 x 35, Slv | Bolt, HHF, Lghtd, M10 x 35, Slv » 103066 M10 x 35mm Black | 4 | $11.75 | Available to order | 4 |
| 3 | 2020073-T0301 Brake Pad Set, x 2 Pads | Brake Pad Set, x 2 Pads | 2 | $65.17 | Available to order | 2 |
| 4 | T2020508 Seal kit | Seal kit | 2 | $109.86 | Available to order | 2 |
| 5 | 2020254-T0301 Piston And Seal Set | Piston And Seal Set | 2 | $245.32 | Available to order | 2 |
| 6 | T2020260 Pad Pin Set | Pad Pin Set | 2 | $23.56 | Available to order | 2 |
| 7 | T2020258 Pad Spring Set | Pad Spring Set | 2 | $21.91 | Available to order | 2 |
| 8 | T2020014 Bleed Screw | Bleed Screw | 2 | $15.84 | Available to order | 2 |
| 9 | T2020982 Brake disc | Brake disc | 2 | $352.59 | Available to order | 2 |
| 10 | T2023233 Bolt, Disc | Bolt, Disc | 12 | $9.73 | Unavailable | View Details |
| 11 | T2020256 Bolt Set, Caliper | Bolt Set, Caliper | 2 | $5.47 | Available to order | 2 |
| 12 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 12 | $4.46 | Available to order | 12 |
